Metal Bellow Expansion Joint Stainless Steel SS316 SS304 Flange and NBR O-ring for Linepipe Application

Metal Bellow Expansion Joint Stainless Steel SS316 SS304 Flange and NBR O-ring for Linepipe Application

    • Metal Bellow Expansion Joint Stainless Steel SS316 SS304 Flange and NBR O-ring for Linepipe Application
    • Metal Bellow Expansion Joint Stainless Steel SS316 SS304 Flange and NBR O-ring for Linepipe Application
    • Metal Bellow Expansion Joint Stainless Steel SS316 SS304 Flange and NBR O-ring for Linepipe Application
  • Metal Bellow Expansion Joint Stainless Steel SS316 SS304 Flange and NBR O-ring for Linepipe Application

    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: BT-SB

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: OFFER
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Contact Now
    Detailed Product Description
    MATERIAL: SS304 COLOR: BLUE

    Metal Expansion Joint Dismantling joint

    SSJA(AF) Dismantling Expansion Joint Flange Loosing Expansion Joint

    SSJB(AY) Dismantling Expansion Joint Gland Loosing Expansion Joint

    SSJB(AY) Two End Covers Type Lapped Steel Expansion Joint

    Two end covers type lapped steel expansion joint at both ends are covers, in the cover channel is trapezoidal sealing ring, after the pipe insert into the sleeve, just tighten the connection bolt;Sealing ring without leakage, no welding, easy installation;Consist of two covers, sleeve, two sealing rings and connecting ties. The only difference between SSJA type is that one end of SSJA is cover, the other end is flange;



    Technical data:

    Pressure scope: 0.25-6.4Mpa

    Size scope: DN65mm-DN4000mm

    Application medium: Air, compressed air, water, sea water, oil, acid, alkali, etc.

    Working temperature: -20-+115 c degree

    Material: Cover- QT400-15, Q235A, ZG230-450,1Cr13, 20#steel

                   Sleeve- Q235A, 20, 16Mn, 1Cr8Ni9Ti

                   Gasket-NBR, CR, FKM, NR

                   Bolt & Nut & Flange - Carbon steel, stainless steel

    Metal Bellows Expansion Joints

    Composed of a metal bellows and flange, which can compensate for thermal and mechanical deformation, and absorb a variety of mechanical vibrations, to reduce distortion and prolong the pipeline’s service life; To compensate the pipeline’s axial, lateral and angular displacement caused by thermal expansion by metal bellow’s expansion and migration, large compensation, good elasticity.

    Technical Data:

    Material: Carbon Steel, Stainless Steel, Ductile Iron

    Working pressure:0.1-2.5 Mpa

    Nominal Diameter: D100-D3000mm

    Fatigue life: 1500 Times

    Applicable Temperature:-20℃~+450℃

    Applicable Medium: Air, compressed air, water, sea water, oil, acid, alkali, etc.
