Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502

  • Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502
  • Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502
  • Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502
  • Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502
  • Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502
Place of Origin China
Brand Name BETTER
Certification API 7K, 6A, 8C, ISO
Model Number CHIKSAN
Minimum Order Quantity 1 SET
Price OFFER
Packaging Details Carton, Plywood Case
Delivery Time 7-10 days
Payment Terms T/T, West Union
Supply Ability Fast Delivery, Plenty in Stock
Product Details
Material Alloy Steel Standard API 6A
Pressure Rating Up To 15000psi
Leave a Message
Product Description

BETTER weco style adapters and integral forged fittings are ideal for handling fluids at cold working pressure up to 20000 psi. Block Tee, elbows, crosses, wyes, laterals can be combined to suit virtually any installation, also union crossover, pup joints, swivel joints, steel loop hose can be provided.



Integral Fitting Longsweep Elbow, Chiksan Longsweep Elblow, Integral unions, belong to the Integral Fittings family. Our union crosses are fully designed, produced, and tested according to API 6A and API 16C standards. These crosses are widely used in cementing, fracturing and testing lines, and other well service applications. Crosses for both standard service and sour service are available. Our Hammer Union Crosses are interchangeable with FMC Weco’s and other major brands.

Fitting Type Size Configuration End Connection CWP Psi Part No. Weight kgs
Longsweep EIblow 2 MxF Fig.1502 10000 3260438 12.3
Longsweep EIblow 3 MxF Fig.1502 10000 3262406 23
Lateral 2 FxMxF Fig.1502 10000 P500724 24.4
Lateral 2 MxFxF Fig.1502 10000 3261421 24.4
Wye 2 MxFxF Fig.1502 10000 3261421 12.3
Wye 2 MxFxF Fig.2202 15000 3248668 12.6
Cross 2 FxFxFxM Fig.1502 10000 3261015 29.4
Cross 2 FxFxMxM Fig.1502 10000 3260888 30.2
Cross 2 MxFxFxF Fig.2202 15000 3259191 34
Cross 2 MxFxMxM Fig.2202 10000 P501752 36.7
Cross 3 FxFxMxF Fig.1502 10000 P501753 85.3
Tee 2 FxFxF Fig.1502 10000 3265042 23
Tee 2 FxFxM Fig.1502 10000 3260359 25.7
Tee 2 FxMxF Fig.1502 10000 3259575 25.7
Tee 2 FxMxM Fig.1502 10000 3259188 29
Tee 2 MxMxF Fig.1502 10000 3263209 29
Tee 2 MxMxM Fig.1502 10000 3265075 33.2
Tee 2 FxMxF Fig.2202 15000 3263266 25.7
Tee 2 FxMxM Fig.2202 15000 3259225 32.2
Tee 3 FxFxM Fig.1502 10000 3265044 76.2
Tee 3 FxMxF Fig.1502 10000 P505146 50.8
Tee 3 MxFxM Fig.1502 10000 P500322 62.1
Tee 3 MxMxF Fig.1502 10000 3263553 62.1
Elbow 2 FxF Fig.1502 10000 3269540 18.6
Elbow 2 MxF Fig.1502 10000 3260360 23.1
Elbow 2 FxM Fig.2202 15000 3264680 23.8
Elbow 3 MxF Fig.1502 10000 3262076 67.1

Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502 0

Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502 1

Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502 2

Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502 3

Long Sweep Elbow Long Radius Elbow Integral Fittings,Integral 90 Degree,FIG 1502 4
