BETTER Drillmax Baker style Float Valves Model G Flapper Type Full Open Valve, GA Differential Pressure Monitoring Valve, Repair Kits

Place of Origin China
Brand Name BETTER
Certification API 7K, 6A, 8C, ISO
Model Number BAKER SPD
Minimum Order Quantity 1 SET
Price USD300.00 PER SET
Packaging Details Carton, Plywood Case
Delivery Time 7-10 days
Payment Terms T/T, West Union
Supply Ability Fast Delivery, Plenty in Stock

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
TYPE F, G, FA, GA Material Alloy Steel
Color Blue, Yellow, Red, Black, Etc
Leave a Message
Product Description

BETTER provides Float Valves, Repair Kits, Baffle Plates and Puller Assembly Tools, including H2S and high temperature service condition. This Drill Pipe Float Valve provides added blowout protection at the bottom of the drillstring, prevent flowback when joints are added, and keep cuttings out of drill pipes to prevent bit plugging while making connections.


Feature

  • All BETTER Float Valves are manufactured with alloy steel integral.
  • All Flappers are investment cast and then case hardened for wear resistance.
  • Elastomers available Buna-N/NBR (Standard), /FKM (Hi-Temp), HNBR (H2S) for optional.
  • All BETTER Float Valves, baffle plates, and valve pullers are interchangeable with the Baker® Style Model F/FA, and Baker® Style Model G/GA Float Valves.
  • Heat Treatment: Carburize at 1500-1550°F to .005/.010 depth with hardness 58 HRC Min.
  • Surface treatment: Xylan fluoropolymer coating with depth 0.25-0.30mm or Nicked Plated.
  • Standard API NRV
  • Color Blue or Black, or customized.

Specification


BETTER Drillmax Baker style Float Valves Model G Flapper Type Full Open Valve, GA Differential Pressure Monitoring Valve, Repair Kits 0

Valve
Size
D
Diameter of
Valve
R(D+1/32)
Diameter of
Recess
for Valve
L
Length of Valve
T*
Diameter of
Recess for
Baffle Plate
ID of Valve
Model F Model G
in. in. in. in. in. in.
1R 1-21/32 1-11/16 5-7/8 1-5/16 1 N/A
1F-2R 1-29/32 1-15/16 6-1/4 1-1/2 1-1/4 1
2F-3R 2-13/32 2-7/16 6-1/2 1-29/32 1-9/16 1-1/4
3F 2-13/16 2-27/32 10 2-7/16 1-7/8 1-5/8
3-1/2 IF 3-1/8 3-5/32 2-11/16
4R 3-15/32 3-1/2 8-5/16 2-15/16 2-5/16 1-31/32
4F 3-21/32 3-11/16 12 3-1/4 2-1/2 2-3/16
5R 3-7/8 3-29/32 9-3/4 3-3/8 2-3/4 2-1/4
5F-6R 4-25/32 4-13/16 11-3/4 4-9/32 3-1/4 2-7/8
6F 5-11/16 5-23/32 14-5/8 5-3/16 4-1/8 N/A

Model G

SIZE ASSEMBLY
PN
WTS
(lbs)
RUBBER REPAIR
KIT-PN
WTS
(Ibs)
METAL REPAIR
KIT-P/N
WTS
(Ibs)

1F

2R

1510422
480151422
2.0 9880300
051988300
.5 9880400
051988400
.7
2F
3R
1520432
480152432
3.5 0130800
016013800
.6 0130200
016013200
.8
3F 1530400
480153400
5.0 0130900
016013900
1.0 0130300
016013300
1.0

31/2

IF

1530600
480153600
6.0 9820000
051982000
1.0 0700200
052070200
1.0
4R 1540200
480154200
7.0 0140000
016014000
1.5 0130400
016013400
1.1

4F



1540400
480154400
8.0 0140100
016014100
1.6 0130500
016013500
1.4

5R



1550200
480155200
9.0 0140200
016014200
1.6 0130600
016013600
1.6

5F

6R

1550462
480155462
18.0 0140300
016014300
2.0 0130700
016013700
1.8



Model GA

SIZE ASSEMBLY
PN
WTS
(lbs)
RUBBER REPAIR
KIT-PN
WTS
(Ibs)
METAL REPAIR
KIT-P/N
WTS
(Ibs)

1F

2R

1620422
480161422
2.0 9880300
051988300
.5 0700800
052070800
.8

2F

3R

1620432
480162432
3.5 0130800
016013800
.6 1350000
017135000
.8
3F 1630400
480163400
5.0 0130900
016013900
1.0 1360700
017136700
1.0
31/2
IF
1630600
480163600
6.0 9820000
051982000
1.0 0750500
052075500
1.0
4R 1640200
480164200
7.0 0140000
016014000
1.5 1160000
017116000
1.1
4F 1640400
480164400
8.0 0140100
016014100
1.6 1360800
017136800
1.4

5R



1650200
480165200
9.0 0140200
016014200
1.6 1360900
017136900
1.6
5F
6R
1650462
480165462
18.0 0140300
016014300
2.0 1360200
017134200
1.8
