BETTER Drillmax Baker style Float Valves Model F Plunger Type Float Valve, Model FA Drill Pipe Float Valve, Repair Kits
| Place of Origin | China |
|---|---|
| Brand Name | BETTER |
| Certification | API 7K, 6A, 8C, ISO |
| Model Number | BAKER SPD |
| Minimum Order Quantity | 1 SET |
| Price | USD300.00 PER SET |
| Packaging Details | Carton, Plywood Case |
| Delivery Time | 7-10 days |
| Payment Terms | T/T, West Union |
| Supply Ability | Fast Delivery, Plenty in Stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| TYPE | F, G, FA, GA | Material | Alloy Steel |
|---|---|---|---|
| Color | Blue, Yellow, Red, Black, Etc |
Product Description
BETTER provides Float Valves, Repair Kits, Baffle Plates and Puller Assembly Tools, including H2S and high temperature service condition. This Drill Pipe Float Valve provides added blowout protection at the bottom of the drillstring, prevent flowback when joints are added, and keep cuttings out of drill pipes to prevent bit plugging while making connections.
Feature
- All BETTER Float Valves are manufactured with alloy steel integral
- All Flappers are investment cast and then case hardened for wear resistance.
- Elastomers available Buna-N/NBR (Standard), /FKM (Hi-Temp), HNBR (H2S) for optional.
- All BETTER Float Valves, baffle plates, and valve pullers are interchangeable with the Baker® Style Model F/FA, and Baker® Style Model G/GA Float Valves.
- Heat Treatment: Carburize at 1500-1550°F to .005/.010 depth with hardness 58 HRC Min.
- Surface treatment: Xylan fluoropolymer coating with depth 0.25-0.30mm or Nicked Plated.
- Standard API NRV
- Color Blue or Black, or customized
Specification
| Valve Size |
D Diameter of Valve |
R(D+1/32) Diameter of Recess for Valve |
L Length of Valve |
T* Diameter of Recess for Baffle Plate |
ID of Valve | |
| Model F | Model G | |||||
| in. | in. | in. | in. | in. | in. | |
| 1R | 1-21/32 | 1-11/16 | 5-7/8 | 1-5/16 | 1 | N/A |
| 1F-2R | 1-29/32 | 1-15/16 | 6-1/4 | 1-1/2 | 1-1/4 | 1 |
| 2F-3R | 2-13/32 | 2-7/16 | 6-1/2 | 1-29/32 | 1-9/16 | 1-1/4 |
| 3F | 2-13/16 | 2-27/32 | 10 | 2-7/16 | 1-7/8 | 1-5/8 |
| 3-1/2 IF | 3-1/8 | 3-5/32 | 2-11/16 | |||
| 4R | 3-15/32 | 3-1/2 | 8-5/16 | 2-15/16 | 2-5/16 | 1-31/32 |
| 4F | 3-21/32 | 3-11/16 | 12 | 3-1/4 | 2-1/2 | 2-3/16 |
| 5R | 3-7/8 | 3-29/32 | 9-3/4 | 3-3/8 | 2-3/4 | 2-1/4 |
| 5F-6R | 4-25/32 | 4-13/16 | 11-3/4 | 4-9/32 | 3-1/4 | 2-7/8 |
| 6F | 5-11/16 | 5-23/32 | 14-5/8 | 5-3/16 | 4-1/8 | N/A |
Model F
| SIZE | ASSEMBLY P/N |
WTS (Ibs) |
RUBBER REPAIR KIT-P/N |
WTS (Ibs) |
METAL REPAIR KIT-P/N |
WTS (Ibs) |
| 1R | 1310200 480131200 |
1.5 | 0120200 016012200 |
.5 | 9290800 015929800 |
1.0 |
| 1F 2R |
1310422 480131422 |
1.5 | 0120300 016012300 |
.7 | 0110300 016011300 |
2.0 |
| 2F 3R |
1320432 480132432 |
2.5 | 0120400 016012400 |
.8 | 0110400 016011400 |
2.0 |
| 3F | 1330400 480133400 |
5.0 | 0120500 016012500 |
1.0 | 0110500 016011500 |
2.0 |
| 31/2 IF |
1330600 480133600 |
6.0 | 0120600 016012600 |
1.0 | 0110500 016011500 |
2.0 |
| 4R | 1340200 480134200 |
7.0 | 0120700 016012700 |
1.0 | 0110700 016011700 |
2.0 |
| 4F | 1340400 480134400 |
10.0 | 0120800 016012800 |
1.0 | 0110800 016011800 |
3.0 |
| 5R | 1350200 480135200 |
9.5 | 0120900 016012900 |
1.0 | 0110900 016011900 |
4.0 |
|
5F 6R |
1350462 480135462 |
19.0 | 0130000 016013000 |
1.1 | 0120000 016012000 |
5.0 |
Model FA
| SIZE | ASSEMBLY P/N |
WTS (Ibs) |
RUBBER REPAIR KIT-P/N |
WTS (Ibs) |
METAL REPAIR KIT-P/N |
WTS (Ibs) |
| 1R | 1310200 480131200 |
1.5 | 0120200 016012200 |
.5 | 9290800 015929800 |
1.0 |
| 1F 2R |
1310422 480131422 |
1.5 | 0120300 016012300 |
.7 | 0110300 016011300 |
2.0 |
| 2F 3R |
1320432 480132432 |
2.5 | 0120400 016012400 |
.8 | 0110400 016011400 |
2.0 |
| 3F | 1330400 480133400 |
5.0 | 0120500 016012500 |
1.0 | 0110500 016011500 |
2.0 |
|
31/2 IF |
1330600 480133600 |
6.0 | 0120600 016012600 |
1.0 | 0110500 016011500 |
2.0 |
| 4R | 1340200 480134200 |
7.0 | 0120700 016012700 |
1.0 | 0110700 016011700 |
2.0 |
| 4F | 1340400 480134400 |
10.0 | 0120800 016012800 |
1.0 | 0110800 016011800 |
3.0 |
| 5R | 1350200 480135200 |
9.5 | 0120900 016012900 |
1.0 | 0110900 016011900 |
4.0 |
|
5F 6R |
1350462 480135462 |
19.0 | 0130000 016013000 |
1.1 | 0120000 016012000 |
5.0 |
