BETTER DEMCO DM TYPE MUD GATE VALVE & Repair Kit 2" 5000 PSI, XXH BW, STD,Equiv. to Cameron J001031-2522110

BETTER could supply DEMCO TYPE mud gate valve and spare parts for 2”,3” 4”@ 2000psi,3000psi, 5000psi.

We also supply DEMCO DM series mud gate valve with below specification:

BETTER Drilling Fluid Equipment Industrial Limited could supply Valve, Gate, Resilient Seated, 4 In (100 Mm), Weld End, Sch Xxh, Demco, Dm, 5000 Psi (344 Bar) Mop, Low Alloy Steel Body, 303 Ss Stem, Alloy Steel/Nickel Plated Gate, Carbon Steel Seat, Buna Seat Seal, Buna Seals, And wheel, Weight 108 Kg; Hs Code: 84818090, Equivalent to Cameron Manufacturer Part Number: J007420-2522110

Gate Valve, 2" 5000 PSI, XXH BW, STD, Equiv. to Cameron J001031-2522110

Gate Valve, 2" SCH160, BW, 5000 PSI, STD, Equiv. to Cameron | J001031-5522110

Gate Valve, 2" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J024929-2582110

Gate Valve, 2" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J024929-2588820

Gate Valve, 3" 5000 PSI, XXH BW, STD, Equiv. to Cameron | J001056-2522110

Gate Valve, 3" 5000 PSI, BW-SCH 160, STD, Equiv. to Cameron | J001056-5522110

Gate Valve, 3" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J025119-2582110

Gate Valve, 3" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J025119-2588820

Gate Valve, 4" 5000 PSI, BW-SCH 160, STD, Equiv. to Cameron | J007420-5522110

Gate Valve, 4" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J025206-2582110

Gate Valve, 4" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J025116-2582120

Gate Valve, 5x4" 5000 PSI, XXH BW, STD, Equiv. to Cameron | J007421-2522110

Gate Valve, 5"x4" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J025118-2582110

Gate Valve, 5x4" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J025118-2588820

All our valves are designed in accordance with API 6A standard and can full interchangeable with famous brands (DEMCO, OTECO, CAMERON, ANSON, and MUDKING), equivalent to DEMCO DM type, OTECO Model 72, CAMERAN FC/FL type, which is applied in Mud pump line, standpipe manifolds, oil and gas pipelines, abrasive drilling mud system, corrosive water flood lines, cementing services, wellheads, and well treating chemicals

Specifications:
Designed specifically for abrasive and erosive condition
Gates available: Nickel-plated carbon steel, Monel, Aluminum Bronze or Stainless Steel
Stainless or Carbon Steel Inserts with Nitrile or HNBR Elastomer
Connection: Flange/Thread/Butt weld/Hammer Union
Pressure ratings 2000psi, 3000psi, 5000 psi in 2", 3", 4", 5" x 4" and 6" x 4" Valve Sizes

Working Temperature: -46°C ~ +121°C

Sour Service Models to NACE MR-01-75
Specification Level: PSL1 ~ PSL4

Performance Requirement: PR1 ~ PR2

Factory Pressure Tested in Accordance with API.6A


We also produce DEMCO DM gate valve parts, major repair kit and minor repair kit, such as STEM SCREW, STEM SCREW SEAL, STEM, SECONDARY SEAL, STEM SEAL ASSEMBLY, BONNET SEAL, GATE, SEAT ASSEMBLY and so on for 2”,3” 4” and 4”x 5” at 2000psi,3000psi, 5000psi.

OEM part no. For reference as below:

Major Repair Kit J025091-10221, J025091-10321, J025091-10421

Minor Repair Kit J025091-00221, J025091-00321, J025091-00421

DEMCO MUD GATE VALVE AND MAJOR / MINOR REPARE KIT

2” 2000PSI FULL PORT Threaded-J001026, Weld-J001029, Grooved-J001920, Flanged-J001023

2” 3000PSI FULL PORT Threaded-J001027, Weld-J001030, Flanged-J001024

2” 5000PSI FULL PORT Threaded-J001028, Weld-J001031, Flanged-J001025

3” 2000PSI FULL PORT Threaded-J001045, Weld-J001054, Grooved-J001922, Flanged-J001036

3” 3000PSI FULL PORT Threaded-J001046, Weld-J001055, Flanged-J001037

3” 5000PSI FULL PORT Threaded-J001047, Weld-J001056, Flanged-J001038

4” 2000PSI FULL PORT Threaded-J001048, Weld-J001057, Grooved-J001923, Flanged-J001039

4” 3000PSI FULL PORT Threaded-J001049, Weld-J001058, Flanged-J001040

4” 5000PSI FULL PORT 4 BOLT BONNET DESIGN Threaded-J007420

4” 5000PSI FULL PORT 12 BOLT BONNET DESIGN Threaded-J017263
