    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: zs703

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: OFFER
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Minimum Order Quantity: 1 PC
    Contact Now
    Detailed Product Description
    Material: Steel API: API & ISO
    High Light:

    MUD SYSTEM

    ZS703 Series 3 panel shale shaker can be used as a primary shale shaker and drying shaker for desander and desilter cones.The linear motion design with Adjustable high G force make ZS703 very popular for any types of drilling including: oil gas drilling, CBM drilling, HDD, water well, geothermal well drilling mud cleaning. The simple but heavy duty design makes GNZS703 shale shaker have reliable operation with less maintenance.









    Shale shaker is the first phase solids control equipment in drilling mud system, also the core equipment for the solids control system. GN provides tandem shale shaker and triple combination shale shaker, we also provide the third generation linear motion shale shaker and the fourth generation balanced elliptical motion shale shaker.









    shale shaker Applications



    (1) OIL&GAS DRILLING----Solids Control System



    (2) HDD & CBM Drilling ----Mud Recycling System



    (3) Mining & Industrial----Slurry Separation Plan







    Complete Line Products



    • Ø  Main Equipment: Shale Shaker, Mud Cleaner ,Desander ,Desilter, Centrifuge, Cutting Dryer ,Agitator, Mixing Hopper, Flare Igniter, Various Tanks, Pumps, Degassers etc.
    • Ø Manufacture all types of shale shaker screens in Asia largest wiremesh center city.



    Parameters



    Model GNZS703E-HB
    Vibration Mode Linear Motion
    Capacity(m³/h) 120(528GPM)
    Vibration Motor(Kw) 2×1.72
    Angle Adjust Motor(Kw) 0.55
    Screen Qty(Pcs) 3
    Screen Size:L×W(mm) 700×1250
    Screen Area( Square meter ) 2.63
    Adjustable G Force ≤7.5G
    Vibration Amplitude(mm) 4.14~5.96
    Deck Angle Range -1~+5°(Electric & Mechanical)
    Feeding Type Weir Feeder
    Weir Height(mm) 895
    EX Standard ExdIIBt4 / IEC EX/ ATEX
    Weight(Kg) 1675
    Dimension:L×W×H(mm) 2717×1998×1428
