Oilfield Drilling Rig Matting Rig Mats

Product Details:

Place of Origin:	China
Brand Name:	BETTER
Certification:	API 7K, 6A, 8C, ISO
Model Number:	BT-SB

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	OFFER
Packaging Details:	Carton, Plywood Case
Delivery Time:	7-10 days
Payment Terms:	T/T, West Union
Supply Ability:	Fast Delivery, Plenty in Stock
Minimum Order Quantity:	1

Contact Now

Detailed Product Description

Material:	Steel And Wood	Packing:	Bulk
High Light:	DRILLING RIG MATTING , STEEL WOOD BASE , RIG MAT

Material:

Steel And Wood

Packing:

Bulk

High Light:

DRILLING RIG MATTING

STEEL WOOD BASE

RIG MAT

BETTER could supply series of drilling rig matting with below features:

Features and benefits:

• Made of steel-frame structure with the excellent hard larch;

• Woodiness is harder than Red pine, better water resistance;

• Standard model steel is used as the steel-frame, loading capacity and cushioning capacity could meet the request on the drilling sites, so as to be qualified to replace the traditional concrete foundation.

• Different size can be manufactured according to the customers’ request.

Application:

• Used as the equipment foundation for drilling rig , Triplex mud pumps, Mud tanks, Power rooms, SRC house, Oil tanks, Water tanks, in order to ensure the steadiness when the drilling equipments is placed at the drilling sites.

• Rig matting are suitable to all kinds of ground surface, especially for loose formation. Directly putting on the ground is available because of large contact area, lower limits to the ground. When the ground loading capacity ≥0.06Mpa, and ground flatness ≤40mm, the rig matting can be working.

Specification (Length x Width x Height mm):

2500×2000×180;

2500×2000×210;

3000×1000×180;

3000×1000×210;

3400×2000×180;

3400×2000×210;

3550×2000×180;

4000×2000×180;

4000×2000×210;

4000×2700×180;

5000×2000×180;
