BETTER Spacesaver closed-coupled Centrifugal Pump3X2X13 Mission Style for Oilfield Application

BETTER Spacesaver closed-coupled Centrifugal Pump3X2X13 Mission Style for Oilfield Application

    • BETTER Spacesaver closed-coupled Centrifugal Pump3X2X13 Mission Style for Oilfield Application
    • BETTER Spacesaver closed-coupled Centrifugal Pump3X2X13 Mission Style for Oilfield Application
    • BETTER Spacesaver closed-coupled Centrifugal Pump3X2X13 Mission Style for Oilfield Application
    • BETTER Spacesaver closed-coupled Centrifugal Pump3X2X13 Mission Style for Oilfield Application
  • BETTER Spacesaver closed-coupled Centrifugal Pump3X2X13 Mission Style for Oilfield Application

    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: Spacesaver

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: USD2500.00-2600.00 PER SET
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Contact Now
    Detailed Product Description
    Theory: Centrifugal Pump Structure: Single-stage Pump
    Usage: Slurry Power: Electric
    Standard Or Nonstandard: Standard Fuel: Motor
    Pressure: Low Pressure Application: Sewage
    Feature: For Limited Space Application

    BETTER BT-SB Spacesaver series centrifugal pump has a very small foot print for applications where space is a premium. These heavy duty pumps require minimum mounting space and are close-coupled, eliminating couplings and coupling alignment considerations. The SpaceSaver pump has proven in mud pump liner coolant service, general rig water supply, micro-tunneling mud mixing and a variety of additional applications.

    • Small foot print design for small space;
    • Full open impeller reduces shaft loading;
    • 3 rings of conventional packing back up standard mechanical seal to provide the utmost reliability and minimal maintenance;
    • Size for 3x2x13, 4x3x13.
    • The pumps can be unitized with Ex-proof electric motors closed-coupling driven configuration.

    BETTER Spacesaver closed-coupled Centrifugal Pump3X2X13 Mission Style for Oilfield Application

    BETTER designs and produces series of heavy-duty centrifugal pumps which is equivalent to all kinds of foreign major brand design, basing on the introduced brand drawings and samples. Though our pump’s function is similar as most of factories made in China, but why we gave up the domestic common design to build a new line:



    1. Mission centrifugal pump line has proven to be the best centrifugal design for handling abrasive mud to compare with other brand centrifugal pumps made in China;

    2. Foreign design pumps deliver superior performance, better longevity, and these pump line offers a broad selection of innovative features for a variety of routine, demanding, abrasive and corrosive applications;

    3. In order to better stand with other popular brand pump existed in the markets, we must make sure our pump and parts compatible with them;

    4. To save or reduce the usage cost for all the users because of all BETTER pumps and parts completely replaceable.

    BUT BETTER COULD PROVIDE A MUCH COMPETITIVE PRICE FOR YOU.

    And,

    All BETTER pumps are build using the excellent quality components, and its parts are 100& identical in all dimensions to Mission™ Magnum™, 2500 supreme™, Halco™ 2500, SPD™ Baker™ Mud Hog™ 2.5, MCM™ 250 series, Double life™ 250, Derick Premium™ 250, XBSY™/Victory/Westpetro, TSC™/HCP, Mattco™, Cobra Pump, Harrisburg™, and Dragon™ 250, etc.



    Common Application

    •Mix and transfer abrasive fluids for drilling industry;

    •Applied in Barite, ferric oxide, mineral oil, base drilling mud, glass fibers, sugar processing, Ash or coal conveyers, cement, mine de-watering, lime slurries, kaolin clay, crystalline forms;

    •Best choice for solid control system or mud cleaning system for land and offshore drilling rigs;

    •Size ranges from 3x2x13, 4x3x13, 5x4x14, 6x5x11, 6x5x14, 8x6x14, 10x8x14 to 14x12x22. Bare pumps, horizontal packages, and overhead belt drive type are available. Explosion-proof electric motors are available up to 350HP, in 1150, 1450, 1750 RPM at 50Hz or 60Hz.



    BETTER now offering:

    Mission Magnum Style

    Mission Sandmaster Hydraulic Drive Style

    Mission Spacesaver Close Coupled Style

    Mission Magnum XP/XL Style

    MCM 250 Style Centrifugal Pump

    SPD Mud Hog 2.5 Style

    Mission Vertical Style

    Shear Pump

    Centrifugal Pump Package Skid

    O.E.M. Pump Interchangeable Spares



    Please don't hesitate to contact our sales if you are interested in any of our products.
    Sales Assistant
    Att.: Mike Lee
    BETTER Drilling Fluid Equipment Industrial Limited
    http://www.drillingfluidsolution.com
    sales[a]drillingfluidequip.com
    WhatsApp/wechat:18764068509



    Complete Bare Pump w/o Motor

    BETTER MODEL SIZE NAME SEALING TYPE IMPELLER SIZE PART NO.
    BT-640202123-ITXX** 3 x 2 x 13 Centrifugal Pump Mechanical Seal 13” 640202123ITA0
    BT-640202222-ITXX** 4 x 3 x 13 Centrifugal Pump Mechanical Seal 13” 640202222ITA0
    BT-640202321-ITXX** 5 x 4 x 14 Centrifugal Pump Mechanical Seal 14” 640202321ITA0
    BT-640202529-ITXX** 6 x 5 x 11 Centrifugal Pump Mechanical Seal 11” 640202529ITA0
    BT-640202628-ITXX** 6 x 5 x 14 Centrifugal Pump Mechanical Seal 14” 640202628ITA0
    BT-640202826-ITXX** 8 x 6 x 11 Centrifugal Pump Mechanical Seal 11” 640202826ITA0
    BT-640202925-ITXX** 8 x 6 x 14 Centrifugal Pump Mechanical Seal 14” 640202925ITA0
    BT-640203121-ITXX** 10 x 8 x 14 Centrifugal Pump Mechanical Seal 14” 640203121ITA0
