| Place of Origin: | China |
| Brand Name: | BETTER |
| Certification: | API 7K, 6A, 8C, ISO |
| Model Number: | MCM250 |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | usd55.00 per set |
| Packaging Details: | Carton, Plywood Case |
| Delivery Time: | 7-10 days |
| Payment Terms: | T/T, West Union |
| Supply Ability: | Fast Delivery, Plenty in Stock |
| Theory: | Centrifugal Pump | Structure: | Single-stage Pump |
|---|---|---|---|
| Usage: | Slurry | Power: | Electric |
| Standard Or Nonstandard: | Standard | Fuel: | Motor |
| Pressure: | Low Pressure | Application: | Sewage |
| Gasket, casing | 10399-46-1 | 10399-46-1 | 648403012 | TP-P25HSN | 17648 | 13C-250-HGA | 052137100 | P25HG | H10399-46-1 |
| Fluid end gasket kit | 10399-46-1A | 10399-46-1A | 641101076 | P25FEGK | 17690 | 31-250-FEGK | 052145400 | P25FEGK | 10399-46-1A |
Fluid end Gasket kits and Power end Gasket kits that includes Casing Gasket, Impeller Seal, Shaft Sleeve Seal and inboard Bearing Gasket, Outboard Bearing Housing Seal, Outboard Bearing cover Seal
(Part no.:3000200/ 3000700/ 3002100, P25FEGK, 10399-46-1A, 052137100, 641101076, P25FEGK, 17690, 31-250-FEGK, 052145400, P25FEGK, , 641103353,3002800/ 3003700/ 3004100, 20625A, 17692, 32-250-PEGK, 52137400, H20625A
We could produce and supply the equivalent spare parts as below. The given part no. is for confirmation.
3 Plug for breather port WWWX00012 601474737
4 Oil plug WWWX00012 601474737
5 Outboard bearing Labyrinth seal WVIN00262 N/A
6 Outboard bearing cover 052136910 20617
8 Outboard bearing cover bolt WWG31D107 3861-139-4
9 Outboard bearing cover seal WWB248P41 72200017
10 Outboard bearing WWESK7311 648408201S
11 Bearing lock washer WV00W1100 648402105
12 Bearing lock nut WV00N1100 648402055
13 Outboard bearing housing 052136810 20624H
15 Outboard bearing housing adjusting bolt WWG31H1H7 3861-138
16 Outboard bearing housing nut WWJ31H800 658404702
17 Outboard bearing housing seal WWB254H30 648402295
18 Shaft 052133900 646490557
19 Coupling end key WWW00A004 601212392
20 Inboard bearing WWENT5313 2564-3H
21 Inboard bearing cover 052136710 17950
22 Inboard bearing cover gasket 052137400 648408706
23 Inboard bearing cover bolt WWG31H1H7 3861-1H
24 Inboard bearing cover Labyrinth seal WVINM0026 2564-4H
– Inboard oil seal WWW003002 648408300
– Inboard exclusion seal WWW003001 648408409
25 Jack bolts WWG31S28F 2538-1H
27 Casing gasket 052137100 648403012
28 Casing stud WWHS1S3HA 648401115
29 Casing stud nut WWJ11S800 3932-61H
31 Impeller seal WWB032V35 648405082
– Shaft sleeve kit 052137000 641102182
– Ceramic coated shaft sleeve kit 052144200 641102181
32 Mechanical seal kit tungsten/tungsten WVBUF9000 648414308
32 Mechanical seal kit silicon/tungsten WVBUF5000 648414357
32 King packing 052153400 661007008
32 5 ring packing with lantern ring 052153500 661007005
33 Stuffing box cover for mechanical seal 052136410 22223
33 Stuffing box cover for mechanical seal aluminum bronze 052136430 22223-13H
– Stuffing box cover for packed 052144910 20614H
34 Gland assembly bolt 052137280 601102494
35 Stuffing box cover bolt WWG31H187 648401016
36 Packing, 3 ring for mechanical seal 052141500 648402600
37 Gland set 052136500 20622
38 Shaft sleeve seal WWB225V40 648415156
– Casing drain plug 1/4 in. WWWX00012 8505-1
– Fluid end gasket kit 052145400 641101076
– Power end gasket kit 052145500 641103353
– Lock nut replacement kit 052145700 641100409
– Oil seal kit 052149000 641103312
– Deflector WWW003003 641116108
Please don't hesitate to contact our sales if you are interested in any of our products.
