BETTER Mission Magnum 5x4x14 Centrifugal Slurry Pumps Complete
| Place of Origin | China |
|---|---|
| Brand Name | BETTER |
| Certification | API 7K, 6A, 8C, ISO |
| Model Number | Mission Magnum |
| Minimum Order Quantity | 1 SET |
| Price | USD 2000.00-2200.00 PER SET |
| Packaging Details | Carton, Plywood Case |
| Delivery Time | 7-10 days |
| Payment Terms | T/T, West Union |
| Supply Ability | Fast Delivery, Plenty in Stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Painting Color | Can Be Customized, Red | Material | Hard Iron |
|---|---|---|---|
| Sealing Type | Mechanical Seal | Impeller | 14" Open Type |
| Shaft | Heavy Duty 2.5" | Suction Size | 5" |
| Discharge Size | 4" | Driven | Motor Or Diesel Engine |
Product Description
BETTER Mission Magnum Style pump are proven as reliable, heavy-duty, low-cost slurry pumps. Magnum type centrifugal pumps can be used in various of applications, like mud pumping, solids control, dredging, leveling or rig platform (ballast), barite, ferric oxide, mineral oil, base drilling muds, glass fibers, sugar processing, ash or coal conveyers, cement, mud cooling towers, underground construction, desanding and desilting, etc
BETTER Drilling Fluid Equipment offers a complete line of centrifugal sand pumps to suit for all kinds of drilling application. Size ranges from 3x2x13, 4x3x13, 5x4x14, 6x5x11, 6x5x14, 8x6x14, 10x8x14 to 14x12x22. Bare pumps, horizontal packages, and overhead belt drive type are availabe. Explosion-proof electric motors are available up to 350HP, in 1150, 1450, 1750 RPM at 50Hz or 60Hz.
Parameters
| BETTER MODEL | SIZE | NAME | SEALING TYPE | IMPELLER SIZE |
| BT-640202123-ITXX** | 3 x 2 x 13 | Centrifugal Pump | Mechanical Seal | 13” |
| BT-640202222-ITXX** | 4 x 3 x 13 | Centrifugal Pump | Mechanical Seal | 13” |
| BT-640202321-ITXX** | 5 x 4 x 14 | Centrifugal Pump | Mechanical Seal | 14” |
| BT-640202529-ITXX** | 6 x 5 x 11 | Centrifugal Pump | Mechanical Seal | 11” |
| BT-640202628-ITXX** | 6 x 5 x 14 | Centrifugal Pump | Mechanical Seal | 14” |
| BT-640202826-ITXX** | 8 x 6 x 11 | Centrifugal Pump | Mechanical Seal | 11” |
| BT-640202925-ITXX** | 8 x 6 x 14 | Centrifugal Pump | Mechanical Seal | 14” |
| BT-640203121-ITXX** | 10 x 8 x 14 | Centrifugal Pump | Mechanical Seal | 14” |
Features
• Compact heavy-duty frame design for small space;
• Multiple application in the oil and gas industrial;
• Full open impeller reduces shaft loading;
• Replaceable stuffing box cover,
• Available in hard ductile iron, high chrome alloy fluid ends(casing, impeller, wear pad, stuffing box), customized fluid ends in stainless steel or aluminum bronze acceptable;
• Available in 8 different size, 3×2, 4×3, 5×4, 6×5, 8×6, 10×8;
• One-piece concentric and thicker casing with same power end;
• Oil or grease lube available; oil lube is for speeds in excess of 2400rpm; 3500rpm is available for 3x2x13 and 4x3x13 pump;
• Spare parts are interchangeable with the standard model.
• The pumps can be unitized with hydraulic motors driven.
Common Application
• Mud mixing and shearing
• Desanding and desilting
• Degassing
• Supercharging
• Centrifugal feed
• Mud cooling towers
• Wash-down
• Chemical, refinery, industrial, construction and agricultural applications
• Underground Construction
