| Place of Origin: | China |
| Brand Name: | BETTER |
| Certification: | API 7K, 6A, 8C, ISO |
| Model Number: | Mission |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | USD 185.00-568.00 PER SET |
| Packaging Details: | Carton, Plywood Case |
| Delivery Time: | 7-10 days |
| Payment Terms: | T/T, West Union |
| Supply Ability: | Fast Delivery, Plenty in Stock |
| Theory: | Centrifugal Pump | Structure: | Single-stage Pump |
|---|---|---|---|
| Usage: | Slurry | Power: | Electric |
| Standard Or Nonstandard: | Standard | Fuel: | Motor |
| Pressure: | Low Pressure | Application: | Sewage |
| Material: | Hard Iron, High Chrome, Stainless Steel |
Superior Quality Pump Spare Parts
used for Heavy duty Centrifugal Pumps Mission 2500 supreme, Misson Magnum, Halco, MCM250, Doublelife, Mud Hog
| CASINGS ( including studs, nuts and gaskets) | |||||
| Item | Qty | MISSION Part No. |
MISSION Processing# |
Description | Material |
| 1* | 1 | 19203-01-30A | 641101753 | Casing,3*2*13 | QT600-3 |
| 1* | 1 | 19205-01-30A | 641101902 | Casing,4*3*13 | QT600-3 |
| 1* | 1 | 19122-01-30A | 641101456 | Casing,6*5*11 | QT600-3 |
| 1* | 1 | 19123-01-30A | 641101605 | Casing, 6*5*14 | QT600-3 |
| 1* | 1 | 19763-01-30A | 641102157 | Casing, 8*6*11 | QT600-3 |
| 1* | 1 | 19117-01-30A | 641101308 | Casing,8*6*14 | QT600-3 |
| 1* | 1 | 20937-01-30A | 641102322 | Casing,10*8*14 | QT600-3 |
| IMPELLERS | |||||
| Item | Qty | MISSION Part No. |
Description | Material | Remarks |
| 2* | 1 | 19204-XX-30 | Impeller,3*2*13 | QT600-3 | 1. XX-Impeller code-First X equals dia.of impeller in inches minus 4.Therefore 10"=6,9"=5, etc…14"use lettet A; 2. Second X equals frational data in 1/8's.Therefore 1/8"=1, 1/4"=2 ,etc…Thus a 10.5" impeller is coded as 64, 12" impeller is coded as 80, 13.25" impeller is coded as 92 etc… 3. YYY-the metric diameter of impeller, therefore 12" is coede as 305mm, 11" is coded as 280mm. |
| 2* | 1 | 19206-XX-30 | Impeller,4*3*13 | QT600-3 | |
| 2* | 1 | 19121-XX-30 | Impeller,6*5*11 | QT600-3 | |
| 2* | 1 | 19121-XX-30 | Impeller, 6*5*14 | QT600-3 | |
| 2* | 1 | 19121-XX-30 | Impeller, 8*6*11 | QT600-3 | |
| 2* | 1 | 19116-XX-30 | Impeller,8*6*14 | QT600-3 | |
| 2* | 1 | 21867-XX-30 | Impeller,10*8*14 | QT600-3 | |
| Fig. Nº | Description | Qty Req |
MCM | Mission | Halco | Harrisburg |
| 1 | 250 Pedestal | 1 | P25PED | 20618-12-1 | H20618-12-1 | 1-250-PED |
| 2 | 250 Shaft | 1 | P25SHFT | 20612-02-33 | H20612-02-33 | 7-250-416SS |
| 3 | 250 Outboard Bearing Housing | 1 | P25OBBH | 20624-01-01 | H20624-01-01 | 4C-250-BH |
| 4 | 250 Packing Gland | 1 | P25PG | 20622A | H20622A | 9-250-GPA |
| 5 | 250 Inboard Bearing | 1 | P25IBBRG | 20615-1 | H20615-1 | 4B-250-BI |
| 6 | 250 Slinger Ring Water | 1 | P25SRW | 22210-1A | H22210-1A | 23-250-SRW-U |
| 7 | 250 Inboard Bearing Cover | 1 | P25IBBC | 20626A | H20626A | 2B-250-BC |
| 8 | 250 Outboard Bearing | 2 | P25OBBRG | 20616-1 | H20616-1 | 4A-250-BO |
| 9 | 250 Outboard Bearing Cover | 1 | P25OBBC | 20617A | H20617A | -2A-250-BC |
| 10 | 250 Graphite Packing | 1 | P25PMSG | 8264-24-OBA | H8264-24-OBA | 8A-250-PMSG |
| - | 250 king Packing | 1 | P25PMSK | 8474-24-1A | H8474-24-1A | 8C-250-PMSK |
| - | 250 Teflon Packing | 1 | P25PMST | 8264-24-7A | H8264-24-7A | 8D-250-PMSK |
| - | 250 Mechanical Seal | 1 | P25MS/TT | 22451 | H22451 | 34A-250-MSI |
| 11 | 250 Gland Bolt Assembly | 2 | P25GABA | 3701A | H3701A | 10-250-GABA- |
| 12 | 250 Shaft Sleeve, Ceramic | 1 | P25SHSLVC | 20613-21G-7A | H20613-21G-7A | 7A-250-SSC |
| 13 | 250 Stuffing Box F/Packing | 1 | P25SB/PK | 20614-01-30 | H20614-01-30 | 11-250-SBPS- |
| - | 250 Stuffing Box F/Mech. Seal | 1 | P25SB/MS | 22223-01-30A | H22223-01-30A | 11C-250-SBMSS |
| 14 | 250-2X3X13 Impeller | 1 | P25D233MRXXX | 19204-XX-30 | H19204-XX-30 | 122523IXXX |
| - | 250-3X4X13 Impeller | 1 | P25D343MRXXX | 19206-XX-30 | H19206-XX-30 | 122534IXXX |
| - | 250-4X5X14 Impeller | 1 | P25D454MRXXX | 19224-XX-30 | H19224-XX-30 | 122545IXXX |
| - | 250-5X6X11 Impeller | 1 | P25D561MRXXX | 19121-XX-30 | H19121-XX-30 | 122556IXXX |
| - | 250-5X6X14 Impeller | 1 | P25D564MRXXX | 19121-XX-30 | H19121-XX-30 | 122564XXX |
| - | 250-5X6X11 Impeller | 1 | P25D681MRXXX | 19116-XX-30 | H19116-XX-30 | 1225681XXX |
| - | 250-6X8X14 Impeller | 1 | P25D684MRXXX | 19116-XX-30 | H19121-XX-30 | 122568IXXX |
| 15 | 250-2X3X13 Housing Assembly | 1 | P25D233H | 19203-01-30A | H19203-01-30A | 142523HAS |
| - | 250-3X4X13 Housing Assembly | 1 | P25D343H | 19203-01-30A | H19205-01-30A | 142534HAS |
| - | 250-4X5X14 Housing Assembly | 1 | P25D454H | 19222-01-30A | H19222-01-30A | N/A |
| - | 250-5X6X11 Housing Assembly | 1 | P25D561H | 19122-01-30A | H19122-01-30A | 1425561HAS-11 |
| - | 250-5X6X14 Housing Assembly | 1 | P25D56H | 19123-01-30A | H19123-01-30A | 1425561HAS-14 |
| - | 250-6X8X11 Housing Assembly | 1 | P25D681H | 19763-01-30A | H19763-01-30A | N/A |
| - | 250-6X8X14 Housing Assembly | 1 | P25D684H | 19117-01-30A | H19117-01-30A | 142568HAS |
| 16 | 250 Housing Stud W/Nut | 12 | P25HSN | 3862-76/ 3932-61 | H3862-76/ 3932-61 | 15-250-HSN |
| 17A | 250 Fluid End Gasket Kit | - | P25FEGH | 10399-46-1A | H10399-46-1A | 31-250-FEGK |
| 17 | 250 Housing Gasket | 1 | P25HG | 10399-46-1 | H10399-46-1 | 13C-250-HGA |
| 18 | 250 Impeller Seal - Oring | 1 | P25IMS | 19110-72 | H19110-72 | 12B250-ISOR |
| 19 | 250 Shaft Sleeve Seal - Oring | 1 | P25SSS | 7496-236 | H7496-236 | 7B-250-SSOR |
| 20A | 250 Oil Seal Kit | - | P250SK | 20619A | H20619A | 33-250-GSK |
| 20 | 250 Inboard Bearing Oil Seal | 1 | P25IBBOS | 20619-01 | H20619-01 | 5B-250-OGSI |
| 21 | 250 Inboard Bearing Oil Seal | 1 | P25IBBOS | 20620-01 | H0620-01 | 5B-250-SEXI |
| 22 | 250 Outboard Bearing Oil Seal | 1 | P25OBBOS | 20619-02 | H20619-02 | 5A-250-OGSO |
| 23A | 250 Power End Gasket Kit | - | P25PEGK | 20625A | H20625A | 32-250-PEGK |
| 23 | 250 Inboard Bearing Cover Gasket | 1 | P25IBBCG | 20625 | H20625 | 3A-250-BCG |
| 24 | 250 Outbd. Bearing Hsg. Seal-Oring | 1 | P25OBBHS | 7496-253 | H7496-253 | 4D-250-BHOR |
| 25 | 250 Outbd. Brg. Cover Seal-Oring | 1 | P25OBBCS | 7496-26 | H7496-26 | 3B-250-BCOR |
| 26 | 250 Bearing Lock Nut Kit | 1 | P25BLNK | 6123-4A | H6123-4A | 4E-250-BBLNA |
| Note: XX or XXX Indicates Impeller Size | ||||||
