MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H

MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H

    • MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H
    • MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H
    • MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H
    • MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H
    • MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H
  • MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H

    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: BT-SBM

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: OFFER
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Minimum Order Quantity: 1 SET
    Contact Now
    Detailed Product Description
    Feature: 100% Interchangeable With Foreign Brand Material: Hard Iron, High Chrome, Stainless Steel
    Structure: Single Stage, Centrifugal Application: Charging, Mixing, Mud, Slurry
    Driven: Diesel, Motor, Hydraulic

    MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H

    BETTER could provide a wide range of open type impeller and semi open impeller, casing, stuffing box, wear pad for all series and brands of heavy duty centrifugal pumps, we have improved the original design with hydraulic hole one impeller position, which have prolonged the impellers' life greatly.

    We have ductile iron, hard iron, high chrome iron material for option, if the quantity is ok, we accept to the customized impeller in bronze, stainless steel and other special material not popular used.

    All impellers are investment casted or resin-casted with pickling (acid washing) as our power-end parts, which are also available in cast steel in favor of ductile. All other sizes are resin-casted with pickling (acid washing) to ensure smooth surface finish. To ensure quality, we meticulously check threaded holes by fitting their bolts to ensure the threads are clean and clear. All casings are of course pressure tested and all impellers and dynamic balanced. Each casing is properly pressure tested prior to shipping.
    It is our standard to deliver all of our impellers in foam molded packing in boxes. If your company has any specific packaging requirements, from branding of castings to box labels, please let us know.



    Casing,3×2×13, H19203-01-30A , 641101753, P25D233H, 1769-002, 142523HAS, 052134000

    Casing,4×3×13, H19205-01-30A , 641101902, P25D343H, 17680-002, 142534HAS, 052134100

    Casing,5×4×14, H19222-01-30A , 641102058, 17681-002, P25D454H, 052134200

    Casing,6×5×11, H19122-01-30A , 641101456, 17682-002, 142556HAS-11, 052134300

    Casing, 6×5×14, H19123-01-30A, 641101605, 17683-002, 142556HAS-14, P25D564H, 052134400

    Casing, 8×6×11, H19763-01-30A, 641102157, 17684-002, P25D681H, 052134500

    Casing,8×6×14, H19117-01-30A , 641101308, 17685-002, 142568HAS, P25D684H, 052134600

    Casing,10×8×14, H20937-01-30A, 641102322

    Housing Gasket: P25HG, 10399-46-1, 17648, 13C-250-HGA, 720700, 052137100

    Housing Stud w/nut: P25HSN,17649/5327-034, 15-250-HSN, B16092121000048& 19052121000000, WWHS1S3HA & WWJ11S800, H2507-3 & H3932-61



    Impeller,3×2×13, H19204-XX-30, 641215603, 17650-XX-112, 1225231XX, P25D233MRxxx, 05213571X, H2521-90-30

    Impeller,4×3×13,H19206-XX-30, 641217005, 17651-XX-112 , 1225341XX, P25D343MRxxx, 05213581X,H2522-90-30

    Impeller,5×4×14, 19224-XX-30, 641217831, 17652-XX-112, 1225451XX, P25D454MRxxx,05213591X,H2525-AO-30

    Impeller,6×5×11, 19121-XX-30, 641211602, 17653-XX-112, 1225561XX, P25D561MRxxx,05213601X,H2524-70-30

    Impeller, 6×5×14, 19121-XX-30, 641212105, 17654-XX-112, 1225561XX, P25D564MRxxx,05213621, H2524-AO-30

    Impeller, 8×6×11, 19121-XX-30, 641211602, 17655-XX-112, 1225661XX, P25D561MRxxx,05213601X, H2524-70-30

    Impeller,8×6×14, 19116-XX-30, 641209903, 17656-XX-112, 1225681XX, P25D584MRxxx,05213631X, H2525-AO-30

    Impeller,10×8×14, 21867-XX-30, 641221007



    Stuffing box, mech.seal: 22223-01-30, 641116157, 17658-002, 11-250-SBPG, P25SB/MS, 052136410,721350

    Stuffing box, packed: 20614-01-30, 643365042, 17657-002, 11C-250-SBMSS, P25SB/PK, 052144910

    Bolt, stuffing box: 3861-117, 3861-117, 648401016, WWG31H187, H3861-117



    Casing wear pad, 2501-37AH,2502-37AH,2503-37AH,2504-37AH,2505-37AH,2506-37AH,2507-37AH

    H2501-01-30A, H2502-01-30A, H2503-01-30A, H2504-01-30A,H2505-01-30A,H2506-01-30A,H2507-01-30A


    Mission Pump Repair Kit we can supply includes Hard Iron Casing, Casing Gasket, Casing Studs and Nuts

    (part no.: 19203AH ,19205AH,19222AH,19122AH,19123AH,19763AH,19117AH)

    MCM 250 Shaft Sleeve Repair Kit we can supply includes Shaft Sleeve, Impeller Seal and Shaft Sleeve Seal

    (Part no.:641102182)

    Halco 2500 Centrifugal Pump Oil Seal Kits we can supply includes inboard Exclusion Seal, Inboard Oil Seal,and Outboard Oil Seal (Part no.:641103312,3002900/ 3003000/ 3004200, P25OSK, 20619A, 17693, 33-250-GSK, 052149000, H20619A)

    We also cans supply MUD HOG 2.5 Pump Fluid end Gasket kits and Power end Gasket kits that includes Casing Gasket, Impeller Seal, Shaft Sleeve Seal and inboard Bearing Gasket, Outboard Bearing Housing Seal, Outboard Bearing cover Seal

    (Part no.:3000200/ 3000700/ 3002100, P25FEGK, 10399-46-1A, 052137100, 641101076, P25FEGK, 17690, 31-250-FEGK, 052145400, P25FEGK, , 641103353,3002800/ 3003700/ 3004100, 20625A, 17692, 32-250-PEGK, 52137400, H20625A


    Bearing Lock nut kit: 6123-4A, H6123-4A, 641100409, TP-P25BLNK, 17689, 4E-250-BBLNA, P25BLNK, 052145700

    Gland Bolt Assembly: P25GABA, 17686, 10-250-GABA, 720600, 052137280, H3701A, 601102494, 052137280

    Impeller Seal O-Ring: P25IMS, 19110-72, 5530-0032, 12B-250-ISOR, 721480, WWB032V35, H19110-72

    Gland assy., packing: 641103338, 17659, 9-250-GPA, P25PG, 052136500, H20622A, 720590, 052136500

    Deflector assembly: 22210-1A, 22210-1A, 641116108, 17691, 23-250-SRW-U, P25SRW, WWW003003, H22210-1A

    Oil seal, I.B.Brg. Cover: 20619-01, 648408300, TP-P25IBBOS, 5550-005, 5B-250-OGSI, P25IBBOS, WWW003002

    Inboard Bearing Cover: P25IBBC, 20626A, 17671, 2B-250-BC, 720780, 052136710, H17950,644303109, 4A-250-BO,

    Inboard Bearing Cover Gasket: P25IBBCG, 20625, 17672, 3A-250-BCG, 721520, 052137400, H20625, 648408706

    Inboard Exclusion Oil Seal: P251BBES, 20620-01, 5550-006, 5C-250-SEXI, 720370, WWW003001, H20620-01,648408409

    Inboard Bearing: P25IBBRG, 20615-1, 50913-001, 4B-250-BI, 720300, WWENT5313, H20615-1,661009010, 50913-001

    Outboard Bearing Housing: P25OBBH, 20624-01-01, 17673, 4C-250-BH, 720800, 052136810, 644308504

    Outboard Bearing Housing O-ring: P25OBBHS, 7496-253, 5530-254, 4D-250-BHOR, 721510, WWB254H30, H7496-253,648402295,32-250-BHOR

    Outboard Bearing Cover: P25OBBC, 20617A, 17866, 2A-250-BC, 720790, 052136910, H20617-01-01,641103296

    Outboard Bearing Cover O-ring: P25OBBCS, 7496-26, 5530-246, 3B-250-BCOR, 720390, WWB248P41, H7496-26,3B-250-BBLNA

    Outboard Bearing Cover Oil Seal: P25OBBOS, 20619-02, 5550-007, 5A-250-OGSO, 720390,648408359, 5550-007, 5A-250-OGSO

    Outboard Bearing: P25OBBRG, 20616-1S, 50912-001, 4A-250-BO, 720320, WWESK7311, H20616-1,648408201S,50912-001, 2A-250-BC


    5A 648414308 22451-1 Seal, Mechanical(Tungsten Carbide Faces)
    5A 648414340 22451-2 Seal, Mechanical(Ceramic Carbon Faces)
    5A 648414357 22451-3 Seal, Mechanical(Silicon to Tungsten Faces)
    5A 22451-9A 22451-9A Seal, Mechanical(Silicon Carbide Faces)
    5A 661007005 25014-04M-B Packing, Shaft, w/latern ring(Graphite)
    5A 661007008 25014-04M-BA Packing, Shaft, w/latern ring(King)
    5A 661007011 250147-04M-D Packing, Shaft, w/latern ring(Teflon)
    5A 661007006 25014-04M-C Packing, Shaft, w/latern ring(Kevlar)
    5A 648408607   Packing, Shaft-M.S. Backup(Graphite)
    5A 648408607   Ring, Latern

    MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H

    MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H

    MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H

    MCM 250 -2X3X13 Housing Assembly P25D233H 3X4X13 P25D343H
