Mission Graphite (backup) Packing 8264-24-OBA

Mission Graphite (backup) Packing 8264-24-OBA

    • Mission Graphite (backup) Packing 8264-24-OBA
    • Mission Graphite (backup) Packing 8264-24-OBA
    • Mission Graphite (backup) Packing 8264-24-OBA
    • Mission Graphite (backup) Packing 8264-24-OBA
  • Mission Graphite (backup) Packing 8264-24-OBA

    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: MISSION MAGNUM, MCM 250

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: usd1500.00 per set
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Contact Now
    Detailed Product Description
    Theory: Centrifugal Pump Structure: Single-stage Pump
    Usage: Slurry Power: 15kw-350kw
    Standard Or Nonstandard: Standard Fuel: Motor
    Pressure: Low Pressure Application: Charging Pump
    Speed: 800-2000 Rpm Color: Regular Blue, And Customized Color Acceptable

    BETTER could provide a wide range of open type impeller and semi open impeller, casing, stuffing box, wear pad for all series and brands of heavy duty centrifugal pumps, we have improved the original design with hydraulic hole one impeller position, which have prolonged the impellers' life greatly.
    We have ductile iron, hard iron, high chrome iron material for option, if the quantity is ok, we accept to the customized impeller in bronze, stainless steel and other special material not popular used.
    All impellers are investment casted or resin-casted with pickling (acid washing) as our power-end parts, which are also available in cast steel in favor of ductile. All other sizes are resin-casted with pickling (acid washing) to ensure smooth surface finish. To ensure quality, we meticulously check threaded holes by fitting their bolts to ensure the threads are clean and clear. All casings are of course pressure tested and all impellers and dynamic balanced. Each casing is properly pressure tested prior to shipping.
    It is our standard to deliver all of our impellers in foam molded packing in boxes. If your company has any specific packaging requirements, from branding of castings to box labels, please let us know.
    Casing,3×2×13, H19203-01-30A , 641101753, P25D233H, 1769-002, 142523HAS, 052134000
    Casing,4×3×13, H19205-01-30A , 641101902, P25D343H, 17680-002, 142534HAS, 052134100
    Casing,5×4×14, H19222-01-30A , 641102058, 17681-002, P25D454H, 052134200
    Casing,6×5×11, H19122-01-30A , 641101456, 17682-002, 142556HAS-11, 052134300
    Casing, 6×5×14, H19123-01-30A, 641101605, 17683-002, 142556HAS-14, P25D564H, 052134400
    Casing, 8×6×11, H19763-01-30A, 641102157, 17684-002, P25D681H, 052134500
    Casing,8×6×14, H19117-01-30A , 641101308, 17685-002, 142568HAS, P25D684H, 052134600
    Casing,10×8×14, H20937-01-30A, 641102322
    Housing Gasket: P25HG, 10399-46-1, 17648, 13C-250-HGA, 720700, 052137100
    Housing Stud w/nut: P25HSN,17649/5327-034, 15-250-HSN, B16092121000048& 19052121000000, WWHS1S3HA & WWJ11S800, H2507-3 & H3932-61
    Impeller,3×2×13, H19204-XX-30, 641215603, 17650-XX-112, 1225231XX, P25D233MRxxx, 05213571X, H2521-90-30
    Impeller,4×3×13,H19206-XX-30, 641217005, 17651-XX-112 , 1225341XX, P25D343MRxxx, 05213581X,H2522-90-30
    Impeller,5×4×14, 19224-XX-30, 641217831, 17652-XX-112, 1225451XX, P25D454MRxxx,05213591X,H2525-AO-30
    Impeller,6×5×11, 19121-XX-30, 641211602, 17653-XX-112, 1225561XX, P25D561MRxxx,05213601X,H2524-70-30
    Impeller, 6×5×14, 19121-XX-30, 641212105, 17654-XX-112, 1225561XX, P25D564MRxxx,05213621, H2524-AO-30
    Impeller, 8×6×11, 19121-XX-30, 641211602, 17655-XX-112, 1225661XX, P25D561MRxxx,05213601X, H2524-70-30
    Impeller,8×6×14, 19116-XX-30, 641209903, 17656-XX-112, 1225681XX, P25D584MRxxx,05213631X, H2525-AO-30
    Impeller,10×8×14, 21867-XX-30, 641221007

    Stuffing box, mech.seal: 22223-01-30, 641116157, 17658-002, 11-250-SBPG, P25SB/MS, 052136410,721350

    Stuffing box, packed: 20614-01-30, 643365042, 17657-002, 11C-250-SBMSS, P25SB/PK, 052144910

    Bolt, stuffing box: 3861-117, 3861-117, 648401016, WWG31H187, H3861-117



    Casing wear pad, 2501-37AH,2502-37AH,2503-37AH,2504-37AH,2505-37AH,2506-37AH,2507-37AH

    H2501-01-30A, H2502-01-30A, H2503-01-30A, H2504-01-30A,H2505-01-30A,H2506-01-30A,H2507-01-30A


    HousingHousingVaries by size
    Gasket, housing720700
    Stud, housing720830
    Nut, housing720860
    Plug drain721651
    Plug neck721651
     impellerVaries by size
     Bolt impeller721402
     Flat washer, impeller721625
     Bolt stuffing box721400
     Lockwasher, stuffing box721401
     Stuffing box, mechanical seal721350
    Mechanical seal arrangementMechanical seal assembly721540
    Packing, back-up720441
    Plug, cleanout721651
    Packing arangementStuffing box, packed721340
    Packing king720470
    Packing graphite720440
    Packing Teflon720500
    Grease fitting, packing721580
    Shaft sleeve arrangementShaft sleeve, 416ssc721580
    Seal, shaft sleeve721490
    Seal, impeller721480
     Packing gland720590
     Gland bolt assembly720600
     o-ring deflector721500
    Inboard bearing cover assemblyCover, inboard bearing720780
    Seal, inboard bearing exclusion720370
    Seal, inboard bearing cover720380
    Gasket, inboard bearing cover720670
    Bolt, inboard bearing cover720891
    Flat washer, inboard bearing cover720091
    Nut, inboard bearing cover720902
    Grease fitting, inboard bearing720781
    Grease fitting, seal720782
     Bearing inboard720320
     Key, shaft721270
    Outboard bearing housing assemblyHousing, outboard bearing720800
    Seal, outboard bearing housing721510
    Bolt, adjustment, outboard bearing housing720890
    Jam nut720970
    Bolt, attachment, outboard bearing housing721400
     Bearing outboard720320
     Locknut, bearing721560
     Lockwasher, bearing locknut721550
    Outboard bearing cover assemblyCover, outboard bearing720790
    Seal, shaft, outboard bearing cover720390
    Grease fitting, outboard bearing721520
    Bolt attach outboard bearing cover721671

    Mission Graphite (backup) Packing 8264-24-OBAMission Graphite (backup) Packing 8264-24-OBA
