China Kemper Valve Hammerseal Unions 20" Good Quality Gray Painting Customized Packaging

Place of Origin China
Brand Name BETTER
Certification API 7K, 6A, 8C, ISO
Model Number KEMPER
Minimum Order Quantity 1 SET
Price OFFER
Packaging Details Carton, Plywood Case
Delivery Time 7-10 days
Payment Terms T/T, West Union
Supply Ability Fast Delivery, Plenty in Stock

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Alloy Technics Casting
Type Union Connection Welding
Shape Equal Head Code Hexagon
Leave a Message
Product Description

BETTER Mud Tank Union is an updated design based on Air Grip Unions. These tank unions can accept pipe misalignment to finish an excellent connecting and sealing, and installation and uninstall rapidly, which has been widely used in mud tanks, mud tank connecting lines, and pump suction flanges.



BETTER manufactures and supplies unions for mud tanks, Hammerseal Unions, mud tank connecting lines and pump suction flanges. These are manufactured for a maximum line pressure of 150 PSI. The nitrile seal provides compressive seal, the cross-section of the seal designed to provide greater sealing surface. The union is designed to take a maximum of 7° misalignment on the pipe. Sizes which are catered for are 6", 8", 10" and 12", 6", 8" and 10" sizes can be socket welded to pipe or butt welded to tubing. 12" size requires butt weld. BETTER Mud Tank Union is an updated design based on Air Grip Unions. These tank unions can accept pipe misalignment to finish an excellent connecting and sealing, and installation and uninstall rapidly, which has been widely used in mud tanks, mud tank connecting lines, and pump suction flanges.

Both of BETTER Air Union and Tank Union styles are interchangeable with other major brands, Bulldog, C&C Industries, Kemper.

Features

Elongated cross-section of seal ring ensures greater sealing surface when in contact with the pipe makes up with hammer

Molded nitrile seal provides a compression seal

Tank union accepts up to 7 degree pipe misalignment

Available in3, 4, 6, 8, 10, 12, 14, 16, 18 and 20 inch sizes

Part no.: PS300A, PS400A, PS600A, PS800A, PS100A, PS120A, PS130A , PS140A, PS160A, PS180A, PS200A

Large diameter, medium-low voltage and frequently dismantling, rapid installation.





Technical parameter:

1. Medium available: mud, oil, water

2. Medium temperature:0°C~90°C

3. Ambient temperature:-30°C~50°C

4. Medium presssure:0.6Mpa




Type

Connect Pipe O.D.

Female Sub *

Weld to

Mud Tank Union Dimensions in mm

A

B

C

D

E

F

G

H
4-inch
4 ½”(114.3mm)
6”
264
168
150
127
50
155
114
21
6-inch
6 5/8”(168.3mm)
8”
340
219
200
127
50
208
168
21
8-inch
8 5/8”(219.1mm)
10”
343
273
253
127
50
258
219
21
10-inch
10 3/4” (273.1mm)
12”
432
325
305
127
50
311
273
21
12-inch
12 3/4”(323.9mm)
14”
491
355
336
127
50
364
324
21
14-inch
14” (355.6mm)
16”
557
406.4
381
127
50.8
395
356
21
16-inch*
16”(406.4mm)
18”
/
/
/
/
/
/
/
/
18-inch*
18”(457mm)
20”
/
/
/
/
/
/
/
/
20-inch*
20”(508mm)
22”
/
/
/
/
/
/
/
/



China Kemper Valve Hammerseal Unions 20" Good Quality Gray Painting Customized Packaging 0China Kemper Valve Hammerseal Unions 20" Good Quality Gray Painting Customized Packaging 1China Kemper Valve Hammerseal Unions 20" Good Quality Gray Painting Customized Packaging 2
