BETTER Shaft Packing with Latern Ring for Mission, MCM, Baker SPD, TSC centrifugal Pump Teflon, Kevlar, Graphite

BETTER Shaft Packing with Latern Ring for Mission, MCM, Baker SPD, TSC centrifugal Pump Teflon, Kevlar, Graphite

    • BETTER Shaft Packing with Latern Ring for Mission, MCM, Baker SPD, TSC centrifugal Pump Teflon, Kevlar, Graphite
    • BETTER Shaft Packing with Latern Ring for Mission, MCM, Baker SPD, TSC centrifugal Pump Teflon, Kevlar, Graphite
    • BETTER Shaft Packing with Latern Ring for Mission, MCM, Baker SPD, TSC centrifugal Pump Teflon, Kevlar, Graphite
    • BETTER Shaft Packing with Latern Ring for Mission, MCM, Baker SPD, TSC centrifugal Pump Teflon, Kevlar, Graphite
    • BETTER Shaft Packing with Latern Ring for Mission, MCM, Baker SPD, TSC centrifugal Pump Teflon, Kevlar, Graphite
  • BETTER Shaft Packing with Latern Ring for Mission, MCM, Baker SPD, TSC centrifugal Pump Teflon, Kevlar, Graphite

    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: 250

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: usd 85.00 per set
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Minimum Order Quantity: 1 PC
    Contact Now
    Detailed Product Description
    Material: Teflon,Kelvar, Graphite Colar: White, Black
    Structure: 5 Packing Rings With 1 Pvc Latern Ring
    High Light:

    PACKING

    BETTER is specialized in supply series of mud system equipments, also supply all kinds of fluid sealing, which is one of the most critical element of any fluid flow system, including packing, mechanical seals, Non-Metallic Gaskets, Semi-Metallic Gaskets, Metallic Gasket(Ring joint gaskets) for centrifugal pumps, triplex mud pump, plunger pump, BOP, gate valve, flange, pipeline, manifold, etc.

    BETTER Shaft Packing with Latern Ring for Mission, MCM, Baker SPD, TSC centrifugal Pump Teflon, Kevlar, Graphite

    CENTRIFUGAL PUMP BRAIDED PACKINGS & LANTERN RING

    To fit Mission, Harrisburg, MCM, SPD

    Size available:

    1 1/8”, 1 7/8”, 2 1/2”

    Most commonly available in Graphite, Kevlar, Teflon Asbestos, Teflon Synthetic, PTFE, GFO (Teflon Graphite). It can be made especially for your application. King style centrifugal packing (molded lip type) is also available for rotating shafts.

    Material available:

    Kevlar fiber packing

    -Braided by aramid fiber impregnated PTFE emulsion and lubricant processing

    Operating limits:

    Pressure40Mpa

    Temperature: -100~260

    Linear speed:25m/s

    PH value: 3~13

    GFO / Kevlar Interbraid Packing

    -100% GF0 fiber woven packing

    Operating limits:

    Pressure30Mpa

    Temperature: 240~288

    Linear speed:25m/s

    PH value: 0~14

    Carbon Fiber Graphite Packing

    -Braided by carbon fiber impregnated PTFE emulsion and lubricant processing

    Operating limits:

    Pressure35Mpa

    Temperature: -200~350

    Linear speed:25m/s

    PH value: 0~14

    Teflon Graphite Packing

    Kelvar Graphite Packing

    Graphite Synthetic Packing - Non-Asbestos

    Pure Teflon Lubricated Packing

    Teflon Synthetic Packing



    Packing seal with lower cost and wide application, include the size of 3x3, 4x4, 5x5, 6x6, 8x8, 10x10, 11x11, 12x12, 14x14, 16x16, 18x18, 20x20, 22x22, 25x25( 1/8”, 5/32”,3/16”, 1/4”, 5/16”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 3/4”, 7/8”, 1”). Special size can be customized if the quantity is acceptable.



    Description

    Mattco

    P/N

    Harrisburg

    P/N

    SPD

    P/N

    MCM

    P/N

    Gasket, casing 17648 13C-250-HGA 052137100 P25HG
    Fluid end gasket kit 17690 31-250-FEGK 052145400 P25FEGK
    Nut, casing 17649 15-250-HSN WWHS1S3HA P25HSN
    Stud, casing 5327-034 WWJ11S800
    Plug, Casing Drain - - - -
    Plug, flush line - - - -
    Seal, impeller 5530-0032 12B-250-ISOR P25IMS WWB032V35
    Washer, impeller - - - -
    Bolt,impeller lock - - - -
    Stuffing box, mech.seal 17658-002 11-250-SBPG P25SB/MS 052136410
    Stuffing box, packed 17657-002 11C-250-SBMSS P25SB/PK 052144910
    Bolt, stuffing box - - - WWG31H187
    Grease fitting - - - -
    Gland assy., packing 17659 9-250-GPA P25PG 052136500
    Seal, mechanical - - - WVBUF9000
    Packing, Shaft - - - 052153500
    Bolt assy,gland - - - 052137280
    Shaft 17665-001 7-250-416SS P25SHFT 052133900
    Sleeve, shaft, M.S. - - - -
    Sleeve, shaft, Pack 17666-002 11-250SBPG P25SHSLVC 052144200
    Key, shaft - - - WWW00A004
    Seal, shaft sleeve - - - -
    Deflector assembly 17691 23-250-SRW-U P25SRW WWW003003
    Frame, grease lubricated 17670 1-250-PED P25PED 052136610
    Plug, oil drain - - - -
    Bolt, casing jack - - - WWG31S28F
    Plug, Frame Drain - - - -
    Cover, inboard bearing 17671 4A-250-BO P25IBBC 052136710
    Gasket, I.B.Brg. Cover 17672 3A-250-BCG P25IBBCG 052137400
    Power end gasket kit 17692 32-250-PEGK P25PEGK 052145500

    Oil seal, I.B.Brg. Cover



    5550-005 5B-250-OGSI P25IBBOS WWW003002
    Bolt, I.B.Brg. Cover 13669 6-178-BCBNA P78BCBA WWWG31H1H7
    Nut, I.B.Brg.Cover -
    ExclusionSeal,I.B.Brg.Cvr. 5550-006 5C-250-SEXI P251BBES WWW003001
    Grease fitting - - - -
    Bearing, inboard 50913-001 4B-250-BI P25IBBRG WWENT5313
    Housing, O.B.bearing 17673 4C-250-BH P25OBBH 052136810
    Seal, O.B.Brg. housing 5530-254 32-250-BHOR P25OBBHS WWB254H30
    Bolts, O.B.Brg. housing - - - WWG31H1H7
    Nut, O.B.Brg.housing jam - -   WWJ31H800
    Cover,O.B.Bearing - - - 052136910
    Grease zerk, O.B.Brg.Cvr. - - - -
    O-ring, O.B.Brg.Cover 5530-246 3B-250-BBLNA P25OBBCS WWB248P41
    Oil seal, O.B.Brg.Cover 5A-250-OGSO P25OBBOS - -
    Bolt, O.B.Brg.Cover - - - WWG31D107
    Bearing, O.B. 50912-001 2A-250-BC P25OBBRG WWESL7311
    Lockwasher,O.B.Bearing - - - WV00W1100
    Locknut, O.B.Bearing - - - WV00N1100
    Bearing Lock nut kit 17689 4E-250-BBLNA P25BLNK 052145700
    Casing,3×2×13 1769-002 142523HAS P25D233H 052134000
    Casing,4×3×13 17680-002 142534HAS P25D343H 052134100
    Casing,5×4×14 17681-002 N/A P25D454H 052134200
    Casing,6×5×11 17682-002 142556HAS-11 P25D454H 052134300
    Casing, 6×5×14 17683-002 142556HAS-14 P25D564H 052134400
    Casing, 8×6×11 17684-002 N/A P25D681H 052134500
    Casing,8×6×14 17685-002 142568HAS P25D684H 052134600
    Casing,10×8×14 - - - -
    Impeller,3×2×13 17650-XX-112 1225231XX P25D233MRxxx -
    Impeller,4×3×13 17651-XX-112 1225341XX P25D343MRxxx -
    Impeller,5×4×14 17652-XX-112 1225451XX P25D454MRxxx -
    Impeller,6×5×11 17653-XX-112 1225561XX P25D561MRxxx -
    Impeller, 6×5×14 17654-XX-112 1225561XX P25D564MRxxx -
    Impeller, 8×6×11 17655-XX-112 1225661XX P25D561MRxxx -
    Impeller,8×6×14 17656-XX-112 1225681XX P25D584MRxxx -
    Impeller,10×8×14 - - - -


    Please don't hesitate to contact our sales if you are interested in any of our products.
    Sales Assistant
    Att.: Mike Lee
    BETTER Drilling Fluid Equipment Industrial Limited
    http://www.drillingfluidsolution.com
    sales[a]drillingfluidequip.com
    WhatsApp/wechat:18764068509
