TEDA Power Tong Dies Tubing Tong Dies F/XY114/6YB XQ140/12Y Alloy steel 20CrMnTi Phosphating Black color APIK 7k std.
| Place of Origin | China |
|---|---|
| Brand Name | BETTER |
| Certification | API 7K, 6A, 8C, ISO |
| Model Number | XY114/6YB XQ140/12Y |
| Minimum Order Quantity | 1 SET |
| Price | USD5.00 PER SET |
| Packaging Details | Carton, Plywood Case |
| Delivery Time | 7-10 days |
| Payment Terms | T/T, West Union |
| Supply Ability | Fast Delivery, Plenty in Stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Alloy Steel | Hardness | HRC56-62 |
|---|---|---|---|
| Surface | Phosphating | Color | Black |
Product Description
Drilling Fluid Equipment Industrial Limited could supply a wide range of tong dies and inserts, and dedicated to be an expert in this field with our own specialization and valuable experience. All our die and inserts are forged and machined, to provide the accuracy required for today's critical applications. The high grade material selected and professional heat treating process provides a suitable hardness, to ameliorate the performance of wear-resisting and corrosion-resisting to a maximum service life. Phosphating or blasting will be done for the surface treatment. Various tooth patterns are available for specific applications. Custom is available.
Interchangeability Warranty
100% interchangeable with OEM design, including BJ, Varco, Web Wilson, B+V, Woolley, Eckel, Farr, Weatherford, BAASH-ROSS Cavins, TD, Rushi, but more cost-effective!
MANUAL TONG DIES , Coarse, Plain, Blue Diamond tooth
We can supply those tong dies for BJ Type B, DB, B Extend/HT50, HT55, HT65 Manual Tong, Web Wilson AAX, H, Woolley Type Super A, B, B+V BV-55, BV-57, BV-65, BV-80, BJ Type SDD, C, F & LF Manual Tong, BJ Power Casing Tong( 4 ½”-13 3/8”), Woolley Type Super C, Eckel model 850, Web Wilson, B+V BV-25, BV-35, BV-100, Short Die for BJ Type B Manual Tong, BJ Drill Pipe Power Tong, Eckel Power Casing Tong, Farr Power Tongs, BJ Powermatic tong, Farr Power Tong, Weatherford 5 ½” & 7 /8”
Dimension: 1/2” x 1.1/4” x 5.7/8”, 1/2” x 1.1/4” x 5”, 1/2” x 1.1/4” x 3.7/8”, 3/8” x 1” x 3.7/8”
Part No.: 16402-2, 16402-6, 6416039, 4716, 627-185-1578, 16401-2, 16401-6, 16401-1, 16401, 6416020, 4631
103426, 4616, 627-185-1500, 24768-2, 101-251, 337-02-098, 6416012, 24768-8, 24768, 24770-2, 6473, 12-1003, 6400019
POWER TONG DIES , Coarse, Plain, Blue Diamond tooth
BJ Drill Pipe Power Tong, RUSHI Drill Pipe Power Tong ZQ 203-100/125, TD Tubing Power Tong XQ89/3YB, XQ89/3YC, XY114/6YB, XQ140/12Y
Dimension: 1/2” x 1.1/4” x 3.7/8”, 7/16” x 1 ¼” x 3 1/16”, 1 3/16” x 1 ¼” x 3 1/2”
Part No.: 73-78, 89-114, 121-156, 89-141.5
| DIES FOR POWER TONGS | ||
| Tong Type | Model | Pipe Size |
| BJ Drill Pipe Power Tong |
1/2” x 1.1/4” x 3.7/8”
|
/ |
|
RUSHI Drill Pipe Power Tong ZQ 203-100/125 |
7/16” x 1 ¼” x 3 1/16” Blue Diamond |
/ |
|
1 3/16” x 1 ¼” x 3 1/2” Blue Diamond |
/ | |
|
TD Tubing Power Tong XQ89/3YB XQ89/3YC |
Thin | 89 ( 3 ½”) |
| Middle-thick | 73 ( 2 7/8”) | |
| Extra-thick | 60 ( 2 3/8”) | |
|
TD Tubing Power Tong XY114/6YB |
Big arc | 89-141.5(3 ½”-5 ½”) |
| Small arc | 73-78(2 7/8”) | |
|
TD Tubing Power Tong XQ140/12Y |
I | 73-78(2 7/8”) |
| II 3/8” x 1” x 3 7/16” | 89-114(3 ½”-4 ½”) | |
| III | 121-156(4 ¾”-6 1/8”) | |
INSERTS FOR ROTARY SLIPS VARCO MODEL SDS/SDML/SDXL & BAASH-ROSS MODEL DU
Slip dies or slip inserts: 2160, 2161, 2162, 2163, 2164, 2165, 2166, 2167, 2168, 2169, 2170, 7613-A-82, 7613-B-82, 7613-C-82, 7613-FF-81, 7613-A-81, 7613-E-81, 7613-E-82, 7613-G-81, 7613-H-81, 7613-Z-81, 7613-DD-81, 7613-EE-81
Circular Buttons FOR VARCO DRILL COLLAR SLIPS - DCS-S / DCS-R / DCS-L & CASING SLIPS CMS-XL
Circular Buttons: 2620, 2628, 2630, 2627, 2625, 2619, 2631, 2626
DIES FOR VARCO SAFETY CLAMP TYPE –MP, T, WA-T, C, WA-C
Safety clamp dies: 7624-A-21, 7624-A-4, 3310, and 3333
INSERTS FOR BJ SLIP TYPE ELEVATORS “LYT” “MYT” “YT” “HYT” “YC”
Original Part no.: 28772, 24773, 29255, 29256, 29357, 29257, 29258, 29259, 30358, 16441, 16442, BJ16408, 24781, 24779, BJ16407, 24783, 24748
FULL CIRCLE SLIP INSERTS FOR C CHD E CAVINS TUBING SPIDER
Slip Insert 3 ½” x 2 3/8”, 66651-1ST, Slip Insert 3 ½” x 2 7/8”, 66651-2ST, Slip Insert 3 ½” x 3 1/2”, 66651-3ST, Slip Insert 5 ½” x 4 1/2”, 66653-2ST, TC-650-4 1/2” x 4 1/2”, 65653-3, TC-651-4 1/2” x 4”, 65653-2, TC-651-41/2” x 3 1/2”, 65653-1, TC-650-3 1/2” x 3 1/2”, 65625-3, TC-651-3 1/2” x 2 7/8”, 65625-2, TC-651-3 1/2” x 2 3/8”, 65625-1, TC-650-2 1/16” x 2 1/16”, TC-651-2 1/16” x 1.990”, TC-651-2 1/16” x 1.660”, TC-651-2 1/16” x 1.135”
