BETTER DEMCO DM TYPE MUD GATE VALVE, 5x4" 5000 PSI, XXH BW, STD,Alloy Steel, Equiv. to Cameron | J007421-2522110

BETTER DEMCO DM TYPE MUD GATE VALVE, 5x4" 5000 PSI, XXH BW, STD,Alloy Steel, Equiv. to Cameron | J007421-2522110

    • BETTER DEMCO DM TYPE MUD GATE VALVE, 5x4" 5000 PSI, XXH BW, STD,Alloy Steel, Equiv. to Cameron | J007421-2522110
    • BETTER DEMCO DM TYPE MUD GATE VALVE, 5x4" 5000 PSI, XXH BW, STD,Alloy Steel, Equiv. to Cameron | J007421-2522110
    • BETTER DEMCO DM TYPE MUD GATE VALVE, 5x4" 5000 PSI, XXH BW, STD,Alloy Steel, Equiv. to Cameron | J007421-2522110
    • BETTER DEMCO DM TYPE MUD GATE VALVE, 5x4" 5000 PSI, XXH BW, STD,Alloy Steel, Equiv. to Cameron | J007421-2522110
  • BETTER DEMCO DM TYPE MUD GATE VALVE, 5x4" 5000 PSI, XXH BW, STD,Alloy Steel, Equiv. to Cameron | J007421-2522110

    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: 5"X4” 5000PSI, XXH BW, STD

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: USD 500.00 PER SET
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Minimum Order Quantity: 1 PC
    Contact Now
    Detailed Product Description
    Standard Or Nonstandard: Standard Structure: Gate
    Pressure: High Pressure Power: Manual
    Material: Alloy Temperature Of Media: Normal Temperature
    Media: Base

    BETTER could supply DEMCO TYPE mud gate valve and spare parts for 2”,3” 4”@ 2000psi,3000psi, 5000psi.BETTER DEMCO DM TYPE MUD GATE VALVE, 5x4" 5000 PSI, XXH BW, STD,Alloy Steel, Equiv. to Cameron | J007421-2522110

    CONNECTION TYPE DIMENSION 4” FULL PORT DIMENSION 4” FULL PORT
    2000 WP 3000 WP 5000 WP
    Full Port Threaded

    Height-656mm

    Width-330mm

    J001048 J001049/M2049

    Height-740mm

    Width-330mm

    J007420/M8420
    Weld J001057 J001058/M2058 J007421
    Flanged (RTJ)

    Height-656mm

    Width-416mm

    J001039 J001040/M2040

    Height-740mm

    Width-457mm

    M27263
    Flange O.D. 274mm 292mm 311mm
    Flange Bolts-Size 8 – 7/8” 8 – 1 1/8” 8 – 1 1/4”
    Ring Number RTJ R-37 R-37 R-39



    NO. DESCRIPTION MATERIAL PART NO.
    2000/3000 WP 5000 WP
    1 Lube Fitting Steel J005195
    2

    Hub Assembly/

    Handle

    ASTM A536 Ductile Iron 2139714-01 2139481-01
    3 Tube Clear Acrylic / J007459
    4

    Lock handle

    /Stem Cap

    C-1213/ ASTM A536 Ductile Iron J001897 J007411
    5 Key Steel / J005305-10016
    6 Stem Screw C-1213 J001915
    7 Stem Screw Seal Buna-N J005526-227
    8 Screw Housing C-1018 J001958
    9 Stem 303 SS/316 SS J001933-002/J001933-008
    10 Secondary Seal Buna-N J005526-214
    11 Retainer C-1213 J001942
    12 Stem Seal Assembly

    Buna-N

    Viton

    J001951-001

    J001951-006

    16 Bonnet ASTM A487 J001972-XXX
    18 Bonnet Seal Buna-N/Viton

    J005526-438/ J005526-439

    J005531-438/ J005531-439

    19 Gate

    AISI 1045 Nickel Plated

    Cast SS ASTM A351 Grade CF8M

    J001926-002

    J001926-008

    20 Body A487
    21 Seat Assembly

    Inserts: Ductile Iron/Steel AISI C1040/316 SS

    Elastomers: Buna-N Viton

    J002207-021/J002207-022

    J002207-081J002207-082

    22 Pin, Lock Handle Steel J005420-18732
    23 Bonnet Stud ASTM A193 J002072
    24 Bonnet Stud Nut ASTM A194 2709000-09-01
    25 Body Stud ASTM A193 J002074
    26 Body Stud Nut ASTM A194 2709000-10-01
    NOTE Major Repair Kit J025091-10421/ J025091-11421 (including Gate, Seat, Bonnet Seal, Stem Screw, Stem Screw Seal, Stem, Secondary Seal, Stem Seal Assy.) Minor Repair Kit J025091-00421/ J025091-01421 (including Gate, Seat, Bonnet Seal)



    BETTER Drilling Fluid Equipment Industrial Limited could supply Valve, Gate, Resilient Seated, 4 In (100 Mm), Weld End, Sch Xxh, Demco, Dm, 5000 Psi (344 Bar) Mop, Low Alloy Steel Body, 303 Ss Stem, Alloy Steel/Nickel Plated Gate, Carbon Steel Seat, Buna Seat Seal, Buna Seals, And wheel, Weight 108 Kg; Hs Code: 84818090, Equivalent to Cameron Manufacturer Part Number: J007420-2522110



    We also supply DEMCO DM series mud gate valve with below specification:

    Gate Valve, 2" 5000 PSI, XXH BW, STD, Equiv. to Cameron J001031-2522110

    Gate Valve, 2" SCH160, BW, 5000 PSI, STD, Equiv. to Cameron | J001031-5522110

    Gate Valve, 2" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J024929-2582110

    Gate Valve, 2" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J024929-2588820

    Gate Valve, 3" 5000 PSI, XXH BW, STD, Equiv. to Cameron | J001056-2522110

    Gate Valve, 3" 5000 PSI, BW-SCH 160, STD, Equiv. to Cameron | J001056-5522110

    Gate Valve, 3" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J025119-2582110

    Gate Valve, 3" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J025119-2588820

    Gate Valve, 4" 5000 PSI, BW-SCH 160, STD, Equiv. to Cameron | J007420-5522110

    Gate Valve, 4" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J025206-2582110

    Gate Valve, 4" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J025116-2582120

    Gate Valve, 5x4" 5000 PSI, XXH BW, STD, Equiv. to Cameron | J007421-2522110

    Gate Valve, 5"x4" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J025118-2582110

    Gate Valve, 5x4" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J025118-2588820



    All our valves are designed in accordance with API 6A standard and can full interchangeable with famous brands (DEMCO, OTECO, CAMERON, ANSON, and MUDKING), equivalent to DEMCO DM type, OTECO Model 72, CAMERAN FC/FL type, which is applied in Mud pump line, standpipe manifolds, oil and gas pipelines, abrasive drilling mud system, corrosive water flood lines, cementing services, wellheads, and well treating chemicals

    Specifications:
    Designed specifically for abrasive and erosive condition
    Gates available: Nickel-plated carbon steel, Monel, Aluminum Bronze or Stainless Steel
    Stainless or Carbon Steel Inserts with Nitrile or HNBR Elastomer
    Connection: Flange/Thread/Butt weld/Hammer Union
    Pressure ratings 2000psi, 3000psi, 5000 psi in 2", 3", 4", 5" x 4" and 6" x 4" Valve Sizes

    Working Temperature: -46°C ~ +121°C

    Sour Service Models to NACE MR-01-75
    Specification Level: PSL1 ~ PSL4

    Performance Requirement: PR1 ~ PR2

    Factory Pressure Tested in Accordance with API.6A


    We also produce DEMCO DM gate valve parts, major repair kit and minor repair kit, such as STEM SCREW, STEM SCREW SEAL, STEM, SECONDARY SEAL, STEM SEAL ASSEMBLY, BONNET SEAL, GATE, SEAT ASSEMBLY and so on for 2”,3” 4” and 4”x 5” at 2000psi,3000psi, 5000psi.

    OEM part no. For reference as below:

    Major Repair Kit J025091-10221, J025091-10321, J025091-10421

    Minor Repair Kit J025091-00221, J025091-00321, J025091-00421



    DEMCO MUD GATE VALVE AND MAJOR / MINOR REPARE KIT

    2” 2000PSI FULL PORT Threaded-J001026, Weld-J001029, Grooved-J001920, Flanged-J001023

    2” 3000PSI FULL PORT Threaded-J001027, Weld-J001030, Flanged-J001024

    2” 5000PSI FULL PORT Threaded-J001028, Weld-J001031, Flanged-J001025

    3” 2000PSI FULL PORT Threaded-J001045, Weld-J001054, Grooved-J001922, Flanged-J001036

    3” 3000PSI FULL PORT Threaded-J001046, Weld-J001055, Flanged-J001037

    3” 5000PSI FULL PORT Threaded-J001047, Weld-J001056, Flanged-J001038

    4” 2000PSI FULL PORT Threaded-J001048, Weld-J001057, Grooved-J001923, Flanged-J001039

    4” 3000PSI FULL PORT Threaded-J001049, Weld-J001058, Flanged-J001040

    4” 5000PSI FULL PORT 4 BOLT BONNET DESIGN Threaded-J007420

    4” 5000PSI FULL PORT 12 BOLT BONNET DESIGN Threaded-J017263
