Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem

Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem

    • Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem
    • Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem
    • Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem
    • Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem
    • Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem
    • Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem
  • Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem

    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: NE-C

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: USD25-35.00 PER UNIT
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Contact Now
    Detailed Product Description
    Port Size: 2"-12" Standard Or Nonstandard: Standard
    Structure: Butterfly Power: Manual
    Material: Alloy Temperature Of Media: Normal Temperature
    Media: Base Feature: Cameron DEMCO Interchangeable

    DEMCO NE-C style Available in sizes 2”-12”, wafer and lug design

    General style with flange locating holes 2”-64” Wafer and Lug type available, soft seal & hard seal, Handle and wheel operation



    BETTER Butterfly valves available in 2’-12” DN50-DN300, Equivalent to DEMCO NE-C series BFV.

    Water and Lug design, identical with NE-C style 2”-12”

    10 position locking handle

    One piece body to assure high strength and minimum weight, cast in water and lug pattern, rating at ANSI Class 150 (285 psi non-shock)

    Top flange with large mounting area for automatic or manual actuators

    Disc & seat are configured for low pressure drop and high flow coefficients

    Replaceable seat in a wide range of materials of NBR, VITON, EPDM or upon request

    Three drop tight pressure ratings 285psi, 200psi, 50psi; 200psi shutoff is widely used;

    Bi-directional with identical flow-way from either face, easy installation & disassembly, inspection, replacement of parts;

    Application in chemical plants, processing plants, power plants, refineries, shipbuilding, pulp and paper mills, also for heating, ventilation and air condition.

    Low cost and light weight to low pressure water, oil, stream, gas and slurry application.



    Material available:

    Body- Ductile iron, Cast Iron

    Stem-416SS

    Disc-316SS, Aluminum Bronze, Nickle plated Ductile Iron

    Seat-Buna-N, Viton, EPDM, Black Neoprene, Hypalon, Natural Rubber, While Neoprene, or special on request



    Temperature within resilient seat limits

    Buna-N, 0-180 F°, for hydrocarbon or petroleum

    Black Neoprene & While Neoprene, 0-180 F°, for food, beverage, vegetable oil, oxygen

    Viton, +20-300 F°, excellent in harsh chemical and elevated temperatures

    Hypalon, 0-180 F°, excellent in acids and very high chemical resistant

    Natural Rubber, +30-150 F°, for dry material high abrasion resistance, no used for oil

    EPDM, +30-275 F°, for food except of edible oil and milk



    Part no. reference:

    Eg. 6” (150 mm) NE-C, 200 psi, Wafer, Standard Trim with Handle – 22124-1215311

    200 psi 22119 22120 22121 22122 22123 22124 22125 22126 22127

    285 psi 22225 22226 22227 22228 22229 22230 22231 22232 22233

    50 psi 22234 22235 22236 22237 22238 22239 22240 22241 22242

    1112311 1114311 1115311 1122311 1124311 1125311 1212311 1214311 1215311 1222311 1224311 1225311 5112311 5114311 5115311 5122311 5124311 5125311 5212311 5214311 5215311 5222311 5224311 5225311





    Series NE-C, 2”-12” Wafer and Lug In.(mm)
    Description 2 2-1/2 3 4 5 6 8 10 12
    200psi BT22119 BT22120 BT22121 BT22122 BT22123 BT22124 BT22125 BT22126 BT22127
    285psi BT22225 BT22226 BT22227 BT22228 BT22229 BT22230 BT22231 BT22232 BT22233
    50psi BT22234 BT22235 BT22236 BT22237 BT22238 BT22239 BT22240 BT22241 BT22242
    Series NE-I, 2”-12” Wafer and Lug In.(mm)
    Description 2 2-1/2 3 4 5 6 8 10 12
    200psi BT22128 BT22129 BT22130 BT22131 BT22132 BT22133 BT22134 BT22135 BT22136
    285psi BT22252 BT22253 BT22254 BT22255 BT22256 BT22257 BT22258 BT22259 BT22260
    50psi BT22261 BT22262 BT22263 BT22264 BT22265 BT22266 BT22267 BT22268 BT22269
    Series NE-D, 2”-12” Wafer In.(mm)
    Description 2 2-1/2 3 4 5 6 8 10 12
    200psi BT22181 BT22129 BT25093 BT22183 BT22184 BT22185 BT22134 BT22186 BT22136
    285psi BT22279 BT22253 BT25135 BT22281 BT22282 BT22283 BT22258 BT22284 BT22260
    50psi BT22285 BT22262 BT25132 BT22287 BT22288 BT22289 BT22267 BT22290 BT22269
    Series NF-C, 14”-36” Wafer and Lug In.(mm)
    Description 14 16 18 20 24 30 36 / /
    150psi BT23820 BT23821 BT23822 BT23823 BT23824 BT24141 BT24357 / /
    50psi BT24440 BT24441 BT24442 BT24443 BT24444 BT24924 BT25061 / /
    Lug Type Butterfly Valves CAMERON MUDKING DEMCO NE-C NE-I BFV Butterfly Valve Nickle Plate Ductile Iron Disc 416SS stem
