HYC SLIP TYPE ELEVATOR CENTRER LATCH ELEVATOR HIGH ALLOY STEEL FORGED NORMAL TEMP.
Product Details:
Place of Origin: |
China |
Brand Name: |
BETTER |
Certification: |
API 7K |
Model Number: |
HYC |
Payment & Shipping Terms:
Minimum Order Quantity: |
1 SET |
Price: |
USD2500-5000 per piece |
Packaging Details: |
Plywood Case |
Delivery Time: |
20-25 days |
Payment Terms: |
T/T, West Union |
Supply Ability: |
Fast Delivery, Plenty in Stock |
Contact Now
Detailed Product Description
Material: |
Alloy Steel |
Performance: |
Long Service Life |
Advantage: |
Competitive Price |
Quality: |
Strict Inspection, TPI Available |
SLIP TYPE ELEVATORS "Y" SERIES
Varco BJ "Y" Series elevators are conventional slip type elevators for handling tubing and small casing. There are 7 types ranging from 20 to 200 ton capacity and covering pipe sizes from 1.05 to 7 5/8 inchese OD. They feature a four slip design which give an optimum contact on the pipe to prevent bttlenecking and gauge damage.
The Varco BJ "YC" type elevator is capable of handling dual tubing strings. All type "Y" series elevator operate with the latch lock combination for safety. The "MYC" and "YC" provide a 7" and the "HYC" a 10 1/2" of intert contact to grip your casing or tubing.
Technical Specifications |
Size |
Type |
Capacity ton |
Weight |
in |
mm |
lb |
kg |
1.050~ 2 1/16 |
27~73 |
LYT |
20 |
57 |
26 |
1.315~2 7/8 |
33~73 |
MYT |
40 |
148 |
67 |
1.315~3 1/2 |
33~89 |
YT |
75 |
355 |
161 |
2 3/8~3 1/2 |
60~89 |
HYT |
150 |
750 |
336 |
3 1/2~7 |
89~178 |
YC |
75 |
445 |
206 |
3 1/2~7 |
89~178 |
MYC |
125 |
750 |
336 |
2 7/8~7 5/8 |
89~194 |
HYC |
200 |
997 |
452 |
2 7/8~7 5/8 |
89~194 |
HYC AO |
200 |
1465 |
665 |
