China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel

  • China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel
  • China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel
  • China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel
  • China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel
  • China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel
  • China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel
Place of Origin China
Brand Name BETTER
Certification API 7K, 6A, 8C, ISO
Model Number 16402-6 16401-2
Minimum Order Quantity 1 SET
Price USD5.00 PER SET
Packaging Details Carton, Plywood Case
Delivery Time 7-10 days
Payment Terms T/T, West Union
Supply Ability Fast Delivery, Plenty in Stock

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material High Alloy Steel Hardness HRC56-62
Surface Phosphating Color Black
Leave a Message
Product Description

China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel 0

China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel 1



Drilling Fluid Equipment Industrial Limited could supply a wide range of tong dies and inserts, and dedicated to be an expert in this field with our own specialization and valuable experience. All our die and inserts are forged and machined, to provide the accuracy required for today's critical applications. The high grade material selected and professional heat treating process provides a suitable hardness, to ameliorate the performance of wear-resisting and corrosion-resisting to a maximum service life. Phosphating or blasting will be done for the surface treatment. Various tooth patterns are available for specific applications. Custom is available.
Interchangeability Warranty
100% interchangeable with OEM design, including BJ, Varco, Web Wilson, B+V, Woolley, Eckel, Farr, Weatherford, BAASH-ROSS Cavins, TD, Rushi, but more cost-effective!

MANUAL TONG DIES , Coarse, Plain, Blue Diamond tooth
We can supply those tong dies for BJ Type B, DB, B Extend/HT50, HT55, HT65 Manual Tong, Web Wilson AAX, H, Woolley Type Super A, B, B+V BV-55, BV-57, BV-65, BV-80, BJ Type SDD, C, F & LF Manual Tong, BJ Power Casing Tong( 4 ½”-13 3/8”), Woolley Type Super C, Eckel model 850, Web Wilson, B+V BV-25, BV-35, BV-100, Short Die for BJ Type B Manual Tong, BJ Drill Pipe Power Tong, Eckel Power Casing Tong, Farr Power Tongs, BJ Powermatic tong, Farr Power Tong, Weatherford 5 ½” & 7 /8”
Dimension: 1/2” x 1.1/4” x 5.7/8”, 1/2” x 1.1/4” x 5”, 1/2” x 1.1/4” x 3.7/8”, 3/8” x 1” x 3.7/8”
Part No.: 16402-2, 16402-6, 6416039, 4716, 627-185-1578, 16401-2, 16401-6, 16401-1, 16401, 6416020, 4631
103426, 4616, 627-185-1500, 24768-2, 101-251, 337-02-098, 6416012, 24768-8, 24768, 24770-2, 6473, 12-1003, 6400019                                                                                                                                                              China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel 2
POWER TONG DIES , Coarse, Plain, Blue Diamond tooth
BJ Drill Pipe Power Tong, RUSHI Drill Pipe Power Tong ZQ 203-100/125, TD Tubing Power Tong XQ89/3YB, XQ89/3YC, XY114/6YB, XQ140/12Y
Dimension: 1/2” x 1.1/4” x 3.7/8”, 7/16” x 1 ¼” x 3 1/16”, 1 3/16” x 1 ¼” x 3 1/2”
Part No.: 73-78, 89-114, 121-156, 89-141.5
INSERTS FOR ROTARY SLIPS VARCO MODEL SDS/SDML/SDXL & BAASH-ROSS MODEL DU
Slip dies or slip inserts: 2160, 2161, 2162, 2163, 2164, 2165, 2166, 2167, 2168, 2169, 2170, 7613-A-82, 7613-B-82, 7613-C-82, 7613-FF-81, 7613-A-81, 7613-E-81, 7613-E-82, 7613-G-81, 7613-H-81, 7613-Z-81, 7613-DD-81, 7613-EE-81
Circular Buttons FOR VARCO DRILL COLLAR SLIPS - DCS-S / DCS-R / DCS-L & CASING SLIPS CMS-XL
Circular Buttons: 2620, 2628, 2630, 2627, 2625, 2619, 2631, 2626
DIES FOR VARCO SAFETY CLAMP TYPE –MP, T, WA-T, C, WA-C
Safety clamp dies: 7624-A-21, 7624-A-4, 3310, and 3333
INSERTS FOR BJ SLIP TYPE ELEVATORS “LYT” “MYT” “YT” “HYT” “YC”
Original Part no.: 28772, 24773, 29255, 29256, 29357, 29257, 29258, 29259, 30358, 16441, 16442, BJ16408, 24781, 24779, BJ16407, 24783, 24748
FULL CIRCLE SLIP INSERTS FOR C CHD E CAVINS TUBING SPIDER
Slip Insert 3 ½” x 2 3/8”, 66651-1ST, Slip Insert 3 ½” x 2 7/8”, 66651-2ST, Slip Insert 3 ½” x 3 1/2”, 66651-3ST, Slip Insert 5 ½” x 4 1/2”, 66653-2ST, TC-650-4 1/2” x 4 1/2”, 65653-3, TC-651-4 1/2” x 4”, 65653-2, TC-651-41/2” x 3 1/2”, 65653-1, TC-650-3 1/2” x 3 1/2”, 65625-3, TC-651-3 1/2” x 2 7/8”, 65625-2, TC-651-3 1/2” x 2 3/8”, 65625-1, TC-650-2 1/16” x 2 1/16”, TC-651-2 1/16” x 1.990”, TC-651-2 1/16” x 1.660”, TC-651-2 1/16” x 1.135”

INSERTS FOR BJ SLIP TYPE ELEVATORS “LYT” “MYT” “YT” “HYT” “YC”
Slip Type Elevator Model Description Original P/N #/Set
LYT(1.05”- 2 1/16”/ 20 TON) 2 1/16” x 2 1/16” 28772 8
MYT( 1.315”- 2 7/8”/ 40 TON) 2 7/8” X 2 7/8” 24773 8
2 7/8” X 2 3/8” 29255 8
2 7/8” X 2 1/16” 29256 8
2 7/8” X 2” 29357 8
2 7/8” X 1 1/2”(1.9”) 29257 8
2 7/8” X 1 1/4”(1.66”) 29258 8
2 7/8” X 1”(1.315”) 29259 8
YT( 1.315”- 3 1/2”/ 75 TON) 2 7/8” X 2 7/8” 24773 12
2 7/8” X 2 3/8” 29255 12
2 7/8” X 2 1/16” 29256 12
2 7/8” X 2” 29357 12
2 7/8” X 1 1/2”(1.9”) 29257 12
2 7/8” X 1 1/4”(1.66”) 29258 12
2 7/8” X 1”(1.315”) 29259 12
3 1/2” X 3 1/2” 24774 24
3 1/2” X 2 7/8” 30358 24
HYT(2 3/8”- 3 1/2”/150 TON) 2 7/8” X 2 7/8” 24773 16
2 7/8” X 2 3/8” 29255 16
2 7/8” X 2 1/16” 29256 16
3 1/2” X 3 1/2” 24774 32
3 1/2” X 2 7/8” 30358 32
YC(3 1/2”-7”/75 TON) 4 1/2” X 4 1/2” BJ16408 16
4 1/2” X 4” 24781 16
4 1/2” X 3 1/2” 24779 16
5 1/2” X 5 1/2” BJ16407 16
5 1/2” X 5” 24783 16
7” x7” BJ16407 24
7” x 6 5/8” 24748 24



China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel 3

China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel 4

China Export Direct Factory Oilfield Tool Tong Dies & Slip Inserts Lug Jaws Manufacturer Good Quality Alloy Steel 5
