    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: KEMPER

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: OFFER
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Minimum Order Quantity: 1
    Contact Now
    Detailed Product Description
    Material: Alloy Technics: Casting
    Type: Union Connection: Welding
    Shape: Equal Head Code: Hexagon

    BETTER Mud Tank Union is an updated design based on Air Grip Unions. These tank unions can accept pipe misalignment to finish an excellent connecting and sealing, and installation and uninstall rapidly, which has been widely used in mud tanks, mud tank connecting lines, and pump suction flanges.



    BETTER manufactures and supplies unions for mud tanks, Hammerseal Unions, mud tank connecting lines and pump suction flanges. These are manufactured for a maximum line pressure of 150 PSI. The nitrile seal provides compressive seal, the cross-section of the seal designed to provide greater sealing surface. The union is designed to take a maximum of 7° misalignment on the pipe. Sizes which are catered for are 6", 8", 10" and 12", 6", 8" and 10" sizes can be socket welded to pipe or butt welded to tubing. 12" size requires butt weld. BETTER Mud Tank Union is an updated design based on Air Grip Unions. These tank unions can accept pipe misalignment to finish an excellent connecting and sealing, and installation and uninstall rapidly, which has been widely used in mud tanks, mud tank connecting lines, and pump suction flanges.

    Both of BETTER Air Union and Tank Union styles are interchangeable with other major brands, Bulldog, C&C Industries, Kemper.

    Features

    Elongated cross-section of seal ring ensures greater sealing surface when in contact with the pipe makes up with hammer

    Molded nitrile seal provides a compression seal

    Tank union accepts up to 7 degree pipe misalignment

    Available in3, 4, 6, 8, 10, 12, 14, 16, 18 and 20 inch sizes

    Part no.: PS300A, PS400A, PS600A, PS800A, PS100A, PS120A, PS130A , PS140A, PS160A, PS180A, PS200A

    Large diameter, medium-low voltage and frequently dismantling, rapid installation.





    Technical parameter:

    1. Medium available: mud, oil, water

    2. Medium temperature:0°C~90°C

    3. Ambient temperature:-30°C~50°C

    4. Medium presssure:0.6Mpa




    Type

    Connect Pipe O.D.

    Female Sub *

    Weld to

    Mud Tank Union Dimensions in mm

    A

    B

    C

    D

    E

    F

    G

    H
    4-inch
    4 ½”(114.3mm)
    6”
    264
    168
    150
    127
    50
    155
    114
    21
    6-inch
    6 5/8”(168.3mm)
    8”
    340
    219
    200
    127
    50
    208
    168
    21
    8-inch
    8 5/8”(219.1mm)
    10”
    343
    273
    253
    127
    50
    258
    219
    21
    10-inch
    10 3/4” (273.1mm)
    12”
    432
    325
    305
    127
    50
    311
    273
    21
    12-inch
    12 3/4”(323.9mm)
    14”
    491
    355
    336
    127
    50
    364
    324
    21
    14-inch
    14” (355.6mm)
    16”
    557
    406.4
    381
    127
    50.8
    395
    356
    21
    16-inch*
    16”(406.4mm)
    18”
    /
    /
    /
    /
    /
    /
    /
    /
    18-inch*
    18”(457mm)
    20”
    /
    /
    /
    /
    /
    /
    /
    /
    20-inch*
    20”(508mm)
    22”
    /
    /
    /
    /
    /
    /
    /
    /
