BETTER DEMCO DM TYPE MUD GATE VALVE, 3" 5000 PSI, BW-SCH 160, STD, Alloy Steel, Equiv. to Cameron | J001056-5522110
| Place of Origin | China |
|---|---|
| Brand Name | BETTER |
| Certification | API 7K, 6A, 8C, ISO |
| Model Number | 3” 5000PSI, SCH160 BW, STD |
| Minimum Order Quantity | 1 SET |
| Price | USD 500.00 PER SET |
| Packaging Details | Carton, Plywood Case |
| Delivery Time | 7-10 days |
| Payment Terms | T/T, West Union |
| Supply Ability | Fast Delivery, Plenty in Stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Standard Or Nonstandard | Standard | Structure | Gate |
|---|---|---|---|
| Pressure | High Pressure | Power | Manual |
| Material | Alloy | Temperature Of Media | Normal Temperature |
| Media | Base |
Product Description
BETTER could supply DEMCO TYPE mud gate valve and spare parts for 2”,3” 4”@ 2000psi,3000psi, 5000psi.
| CONNECTION TYPE | DIMENSION | 3” FULL PORT | ||
| 2000 WP | 3000 WP | 5000 WP | ||
| Full Port Threaded |
Height-557mm Width-279mm |
J001045 | J001046/M2046 | J001047/M2047 |
| Weld | J001054 | J001055/M2055 | J001056/M2056 | |
| Grooved | J011922 | - | - | |
| Flanged (RTJ) |
Height-557mm Width-397mm |
J001036 | J001037/M2037 | J001038/M2038 |
| Flange O.D. | 210mm | 241mm | 267mm | |
| Flange Bolts-Size | 8 – 3/4” | 8 – 7/8” | 8 – 1 1/8” | |
| Ring Number RTJ | R-31 | R-31 | R-35 | |
| NO. | DESCRIPTION | MATERIAL | PART NO. |
| 1 | Lube Fitting | Steel | J005195 |
| 2 | Hub Assembly | ASTM A536 Ductile Iron | 2139713-01 |
| 3 | Pin, Lock Handle | Steel | J005420-18732 |
| 4 | Lock handle | C-1213 | J001892 |
| 6 | Stem Screw Seal | Buna-N | J005526-226 |
| 7 | Screw Housing | C-1018 | J001852 |
| 9 | Stem Screw | C-1213 | J001914-003 |
| 10 | Secondary Seal | Buna-N | J005526-212 |
| 11 | Retainer | C-1213 | J001941 |
| 12 | Stem Seal Assembly | Buna-N/ | J001950-001/J001950-006 |
| 13 | Bonnet | ASTM A105 | J001971-XXX/ J001976-XXX |
| 14 | Stem | 303 SS/316 SS | J001932-002/J001932-008 |
| 15 | Gate | Steel, Nickel Plated/316ss | J001886-002/J001886-008 |
| 16 | Seat Assembly | Inserts: Ductile Iron or Steel or 316 SS Elastomers: Buna-N |
J001878-011/J001878-012 J001878-021/J001878-022 J001878-081/J001878-082 |
| 17 | Bonnet Seal | Buna-N/ | J005526-431/J005531-431 |
| 19 | Body | A487 | - |
| 20 | Bonnet Stud | ASTM A193 | J002066 |
| 21 | Bonnet Stud Nut | ASTM A194 | 2709000-08-01 |
| 22 | Body Stud | ASTM A193 | J002072/ J002074 |
| 23 | Body Stud Nut | ASTM A194 | 2709000-0901/2709000-1001 |
| NOTE |
Major Repair Kit J025091-10321 (including Gate, Seat, Bonnet Seal, Stem Screw, Stem Screw Seal, Stem, Secondary Seal, Stem Seal Assy.) Minor Repair Kit J025091-00321 (including Gate, Seat, Bonnet Seal) |
||
We also supply DEMCO DM series mud gate valve with below specification:
BETTER Drilling Fluid Equipment Industrial Limited could supply Valve, Gate, Resilient Seated, 4 In (100 Mm), Weld End, Sch Xxh, Demco, Dm, 5000 Psi (344 Bar) Mop, Low Alloy Steel Body, 303 Ss Stem, Alloy Steel/Nickel Plated Gate, Carbon Steel Seat, Buna Seat Seal, Buna Seals, And wheel, Weight 108 Kg; Hs Code: 84818090, Equivalent to Cameron Manufacturer Part Number: J007420-2522110
Gate Valve, 2" 5000 PSI, XXH BW, STD, Equiv. to Cameron J001031-2522110
Gate Valve, 2" SCH160, BW, 5000 PSI, STD, Equiv. to Cameron | J001031-5522110
Gate Valve, 2" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J024929-2582110
Gate Valve, 2" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J024929-2588820
Gate Valve, 3" 5000 PSI, XXH BW, STD, Equiv. to Cameron | J001056-2522110
Gate Valve, 3" 5000 PSI, BW-SCH 160, STD, Equiv. to Cameron | J001056-5522110
Gate Valve, 3" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J025119-2582110
Gate Valve, 3" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J025119-2588820
Gate Valve, 4" 5000 PSI, BW-SCH 160, STD, Equiv. to Cameron | J007420-5522110
Gate Valve, 4" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J025206-2582110
Gate Valve, 4" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J025116-2582120
Gate Valve, 5x4" 5000 PSI, XXH BW, STD, Equiv. to Cameron | J007421-2522110
Gate Valve, 5"x4" 5000 PSI, XXH BW, NACE & STD, Equiv. to Cameron | J025118-2582110
Gate Valve, 5x4" 5000 PSI, XXH BW, H2S, Equiv. to Cameron | J025118-2588820
All our valves are designed in accordance with API 6A standard and can full interchangeable with famous brands (DEMCO, OTECO, CAMERON, ANSON, and MUDKING), equivalent to DEMCO DM type, OTECO Model 72, CAMERAN FC/FL type, which is applied in Mud pump line, standpipe manifolds, oil and gas pipelines, abrasive drilling mud system, corrosive water flood lines, cementing services, wellheads, and well treating chemicals
Specifications:
Designed specifically for abrasive and erosive condition
Gates available: Nickel-plated carbon steel, Monel, Aluminum Bronze or Stainless Steel
Stainless or Carbon Steel Inserts with Nitrile or HNBR Elastomer
Connection: Flange/Thread/Butt weld/Hammer Union
Pressure ratings 2000psi, 3000psi, 5000 psi in 2", 3", 4", 5" x 4" and 6" x 4" Valve Sizes
Working Temperature: -46°C ~ +121°C
Sour Service Models to NACE MR-01-75
Specification Level: PSL1 ~ PSL4
Performance Requirement: PR1 ~ PR2
Factory Pressure Tested in Accordance with API.6A
We also produce DEMCO DM gate valve parts, major repair kit and minor repair kit, such as STEM SCREW, STEM SCREW SEAL, STEM, SECONDARY SEAL, STEM SEAL ASSEMBLY, BONNET SEAL, GATE, SEAT ASSEMBLY and so on for 2”,3” 4” and 4”x 5” at 2000psi,3000psi, 5000psi.
OEM part no. For reference as below:
Major Repair Kit J025091-10221, J025091-10321, J025091-10421
Minor Repair Kit J025091-00221, J025091-00321, J025091-00421
DEMCO MUD GATE VALVE AND MAJOR / MINOR REPARE KIT
2” 2000PSI FULL PORT Threaded-J001026, Weld-J001029, Grooved-J001920, Flanged-J001023
2” 3000PSI FULL PORT Threaded-J001027, Weld-J001030, Flanged-J001024
2” 5000PSI FULL PORT Threaded-J001028, Weld-J001031, Flanged-J001025
3” 2000PSI FULL PORT Threaded-J001045, Weld-J001054, Grooved-J001922, Flanged-J001036
3” 3000PSI FULL PORT Threaded-J001046, Weld-J001055, Flanged-J001037
3” 5000PSI FULL PORT Threaded-J001047, Weld-J001056, Flanged-J001038
4” 2000PSI FULL PORT Threaded-J001048, Weld-J001057, Grooved-J001923, Flanged-J001039
4” 3000PSI FULL PORT Threaded-J001049, Weld-J001058, Flanged-J001040
4” 5000PSI FULL PORT 4 BOLT BONNET DESIGN Threaded-J007420
4” 5000PSI FULL PORT 12 BOLT BONNET DESIGN Threaded-J017263
