Power Tong Dies 24768 8260 Black Phosphating Alloy Steel HRC62 API 7K SLIP INSERTS

Place of Origin China
Brand Name Varco
Certification API 7K
Model Number 24768
Minimum Order Quantity 100 sets
Price USD2.5-3.5 PER PIECE
Packaging Details plywood case
Delivery Time 5-7 DAYS
Payment Terms T/T, Western Union
Supply Ability 10000set per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 20CrMoTi Hardness HRC56-62
Surface Treatment Black Phosphating
Leave a Message
Product Description

BETTER could supply a wide range of tong dies and inserts, all our die and inserts are forged and machined, to provide the accuracy required for today's critical applications. The high grade material selected and professional heat treating process provides a suitable hardness, to ameliorate the performance of wear-resisting and corrosion-resisting to a maximum service life. Phosphating or blasting will be done for the surface treatment. Various tooth patterns are available for specific applications. Custom is available.

Interchangeability Warranty

100% interchangeable with OEM design, including BJ, Varco, Web Wilson, B+V, Woolley, Eckel, Farr, Weatherford, BAASH-ROSS Cavins, TD, Rushi, but more cost-effective!

MANUAL TONG DIES , Coarse, Plain, Blue Diamond Tooth

We can supply those tong dies for BJ Type B, DB, B Extend/HT50, HT55, HT65 Manual Tong, Web Wilson AAX, H, Woolley Type Super A, B, B+V BV-55, BV-57, BV-65, BV-80, BJ Type SDD, C, F & LF Manual Tong, BJ Power Casing Tong( 4 ½”-13 3/8”), Woolley Type Super C, Eckel model 850, Web Wilson, B+V BV-25, BV-35, BV-100, Short Die for BJ Type B Manual Tong, BJ Drill Pipe Power Tong, Eckel Power Casing Tong, Farr Power Tongs, BJ Powermatic tong, Farr Power Tong, Weatherford 5 ½” & 7 /8”

Dimension: 1/2 x 1.1/4 x 5.7/8, 1/2 x 1.1/4 x 5, 1/2 x 1.1/4 x 3.7/8, 3/8 x 1 x 3.7/8

Part No.: 16402-2, 16402-6, 6416039, 4716, 627-185-1578, 16401-2, 16401-6, 16401-1, 16401, 6416020, 4631

103426, 4616, 627-185-1500, 24768-2, 101-251, 337-02-098, 6416012, 24768-8, 24768, 24770-2, 6473, 12-1003, 6400019

POWER TONG DIES , Coarse, Plain, Blue Diamond Tooth

We can supply power tong dies for BJ Drill Pipe Power Tong, RUSHI Drill Pipe Power Tong ZQ 203-100/125, TD Tubing Power Tong XQ89/3YB, XQ89/3YC, XY114/6YB, XQ140/12Y in size of 1/2 x 1.1/4 x 3.7/8, 7/16 x 1 ¼ x 3 1/16, 1 3/16 x 1 ¼ x 3 1/2, etc.

Interchangeability warranty

100% interchangeable with OEM design, but more cost-effective!

VARCO BJ equivalent part no:

Blue diamond, , coarse tong dies: 16401, 16401-1, 16401-2, 16401-6, 16402, 16402-1, 16402-2, 16402-6

1/2x 1 1/4x 5 7/8, 1/2x 1 1/4x 5, 1/2x 1 1/4x 3 7/8,

Slip dies or slip inserts: 2160, 2161, 2162, 2163, 2164, 2165, 2166, 2167, 2168, 2169, 2170, 7613-A-82, 7613-B-82, 7613-C-82, 7613-FF-81, 7613-A-81, 7613-E-81, 7613-E-82, 7613-G-81, 7613-H-81, 7613-Z-81, 7613-DD-81, 7613-EE-81

Circular Buttons: 2620, 2628, 2630, 2627, 2625, 2619, 2631, 2626

Safety clamp dies: 7624-A-21, 7624-A-4, 3310, 3333

INSERTS FOR BJ SLIP TYPE ELEVATORS LYT MYT YT HYT YC

28772,24773,29255,29256,29357,29257,29258,29259,24773,29255,29256,29357,29257,29258,29259,24774,30358,

24773,29255,29256,24774,30358,16441/350103,16442,16408/350105,24781/350504,24779/350903,BJ16407/350107,24783/350506,BJ16407/350110,24748/350409

Full Circle Inserts for Cavins Type C & CHD spider

TC-650-2 1/16” x 2 1/16”

TC-651-2 1/16” x 1.990”

TC-651-2 1/16” x 1.660”

TC-651-2 1/16” x 1.135”

TC-650-3 1/2” x 3 1/2”, 65652-3

TC-651-3 1/2” x 2 7/8”, 65652-2

TC-651-3 1/2” x 2 3/8”, 65652-1

TC-650-4 1/2” x 4 1/2”, 65653-3

TC-651-4 1/2” x 4”, 65653-2

TC-651-41/2” x 3 1/2”, 65653-1

66651-1ST

66651-2ST

66651-3ST

66653-2ST

DIES FOR POWER TONGS
Tong Type Model Pipe Size
BJ Drill Pipe Power Tong

1/2” x 1.1/4” x 3.7/8”



/

RUSHI Drill Pipe Power Tong

ZQ 203-100/125

7/16” x 1 ¼” x 3 1/16”

Blue Diamond

/

1 3/16” x 1 ¼” x 3 1/2”

Blue Diamond

/

TD Tubing Power Tong

XQ89/3YB

XQ89/3YC

Thin 89 ( 3 ½”)
Middle-thick 73 ( 2 7/8”)
Extra-thick 60 ( 2 3/8”)

TD Tubing Power Tong

XY114/6YB

Big arc 89-141.5(3 ½”-5 ½”)
Small arc 73-78(2 7/8”)

TD Tubing Power Tong

XQ140/12Y

I 73-78(2 7/8”)
II 3/8” x 1” x 3 7/16” 89-114(3 ½”-4 ½”)
III 121-156(4 ¾”-6 1/8”)



 Power Tong Dies 24768 8260 Black Phosphating Alloy Steel HRC62 API 7K SLIP INSERTS 0
