    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: Mission

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: USD 185.00-568.00 PER SET
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Contact Now
    Detailed Product Description
    Theory: Centrifugal Pump Structure: Single-stage Pump
    Usage: Slurry Power: Electric
    Standard Or Nonstandard: Standard Fuel: Motor
    Pressure: Low Pressure Application: Sewage
    Material: Hard Iron, High Chrome, Stainless Steel

    Superior Quality Pump Spare Parts
    used for Heavy duty Centrifugal Pumps Mission 2500 supreme, Misson Magnum, Halco, MCM250, Doublelife, Mud Hog




    BETTER is experienced in supply a full line of fluid end parts interchangeable with Mission Magnum I, and 2500 Supreme, halco 2500. The equivalent or same materials are selected to guarantee the unified quality. Please refer to the list and tell the part no. or pump model with item description, our sales will offer you in a fast time. We have a plenty of each parts in stork to ensure you a fast delivery. Meanwhile, we accept your customized idea including painting color, logo, nameplate or any you want to try, we are glad to work with you to design.

    Please don't hesitate to contact our sales if you are interested in any of our products.
    Sales Assistant
    Att.: Mike Lee
    BETTER Drilling Fluid Equipment Industrial Limited
    http://www.drillingfluidsolution.com
    sales[a]drillingfluidequip.com
    WhatsApp/wechat:18764068509

    CASINGS ( including studs, nuts and gaskets)
    Item Qty MISSION
    Part No.
    MISSION
    Processing#
    Description Material
    1* 1 19203-01-30A 641101753 Casing,3*2*13 QT600-3
    1* 1 19205-01-30A 641101902 Casing,4*3*13 QT600-3
    1* 1 19122-01-30A 641101456 Casing,6*5*11 QT600-3
    1* 1 19123-01-30A 641101605 Casing, 6*5*14 QT600-3
    1* 1 19763-01-30A 641102157 Casing, 8*6*11 QT600-3
    1* 1 19117-01-30A 641101308 Casing,8*6*14 QT600-3
    1* 1 20937-01-30A 641102322 Casing,10*8*14 QT600-3
    IMPELLERS
    Item Qty MISSION
    Part No.
    Description Material Remarks
    2* 1 19204-XX-30 Impeller,3*2*13 QT600-3 1. XX-Impeller code-First X equals dia.of impeller in inches minus 4.Therefore 10"=6,9"=5, etc…14"use lettet A;
    2. Second X equals frational data in 1/8's.Therefore 1/8"=1, 1/4"=2 ,etc…Thus a 10.5" impeller is coded as 64, 12" impeller is coded as 80, 13.25" impeller is coded as 92 etc…
    3. YYY-the metric diameter of impeller, therefore 12" is coede as 305mm, 11" is coded as 280mm.
    2* 1 19206-XX-30 Impeller,4*3*13 QT600-3
    2* 1 19121-XX-30 Impeller,6*5*11 QT600-3
    2* 1 19121-XX-30 Impeller, 6*5*14 QT600-3
    2* 1 19121-XX-30 Impeller, 8*6*11 QT600-3
    2* 1 19116-XX-30 Impeller,8*6*14 QT600-3
    2* 1 21867-XX-30 Impeller,10*8*14 QT600-3
    Fig. Nº Description Qty
    Req
    MCM Mission Halco Harrisburg
    1 250 Pedestal 1 P25PED 20618-12-1 H20618-12-1 1-250-PED
    2 250 Shaft 1 P25SHFT 20612-02-33 H20612-02-33 7-250-416SS
    3 250 Outboard Bearing Housing 1 P25OBBH 20624-01-01 H20624-01-01 4C-250-BH
    4 250 Packing Gland 1 P25PG 20622A H20622A 9-250-GPA
    5 250 Inboard Bearing 1 P25IBBRG 20615-1 H20615-1 4B-250-BI
    6 250 Slinger Ring Water 1 P25SRW 22210-1A H22210-1A 23-250-SRW-U
    7 250 Inboard Bearing Cover 1 P25IBBC 20626A H20626A 2B-250-BC
    8 250 Outboard Bearing 2 P25OBBRG 20616-1 H20616-1 4A-250-BO
    9 250 Outboard Bearing Cover 1 P25OBBC 20617A H20617A -2A-250-BC
    10 250 Graphite Packing 1 P25PMSG 8264-24-OBA H8264-24-OBA 8A-250-PMSG
    - 250 king Packing 1 P25PMSK 8474-24-1A H8474-24-1A 8C-250-PMSK
    - 250 Teflon Packing 1 P25PMST 8264-24-7A H8264-24-7A 8D-250-PMSK
    - 250 Mechanical Seal 1 P25MS/TT 22451 H22451 34A-250-MSI
    11 250 Gland Bolt Assembly 2 P25GABA 3701A H3701A 10-250-GABA-
    12 250 Shaft Sleeve, Ceramic 1 P25SHSLVC 20613-21G-7A H20613-21G-7A 7A-250-SSC
    13 250 Stuffing Box F/Packing 1 P25SB/PK 20614-01-30 H20614-01-30 11-250-SBPS-
    - 250 Stuffing Box F/Mech. Seal 1 P25SB/MS 22223-01-30A H22223-01-30A 11C-250-SBMSS
    14 250-2X3X13 Impeller 1 P25D233MRXXX 19204-XX-30 H19204-XX-30 122523IXXX
    - 250-3X4X13 Impeller 1 P25D343MRXXX 19206-XX-30 H19206-XX-30 122534IXXX
    - 250-4X5X14 Impeller 1 P25D454MRXXX 19224-XX-30 H19224-XX-30 122545IXXX
    - 250-5X6X11 Impeller 1 P25D561MRXXX 19121-XX-30 H19121-XX-30 122556IXXX
    - 250-5X6X14 Impeller 1 P25D564MRXXX 19121-XX-30 H19121-XX-30 122564XXX
    - 250-5X6X11 Impeller 1 P25D681MRXXX 19116-XX-30 H19116-XX-30 1225681XXX
    - 250-6X8X14 Impeller 1 P25D684MRXXX 19116-XX-30 H19121-XX-30 122568IXXX
    15 250-2X3X13 Housing Assembly 1 P25D233H 19203-01-30A H19203-01-30A 142523HAS
    - 250-3X4X13 Housing Assembly 1 P25D343H 19203-01-30A H19205-01-30A 142534HAS
    - 250-4X5X14 Housing Assembly 1 P25D454H 19222-01-30A H19222-01-30A N/A
    - 250-5X6X11 Housing Assembly 1 P25D561H 19122-01-30A H19122-01-30A 1425561HAS-11
    - 250-5X6X14 Housing Assembly 1 P25D56H 19123-01-30A H19123-01-30A 1425561HAS-14
    - 250-6X8X11 Housing Assembly 1 P25D681H 19763-01-30A H19763-01-30A N/A
    - 250-6X8X14 Housing Assembly 1 P25D684H 19117-01-30A H19117-01-30A 142568HAS
    16 250 Housing Stud W/Nut 12 P25HSN 3862-76/ 3932-61 H3862-76/ 3932-61 15-250-HSN
    17A 250 Fluid End Gasket Kit - P25FEGH 10399-46-1A H10399-46-1A 31-250-FEGK
    17 250 Housing Gasket 1 P25HG 10399-46-1 H10399-46-1 13C-250-HGA
    18 250 Impeller Seal - Oring 1 P25IMS 19110-72 H19110-72 12B250-ISOR
    19 250 Shaft Sleeve Seal - Oring 1 P25SSS 7496-236 H7496-236 7B-250-SSOR
    20A 250 Oil Seal Kit - P250SK 20619A H20619A 33-250-GSK
    20 250 Inboard Bearing Oil Seal 1 P25IBBOS 20619-01 H20619-01 5B-250-OGSI
    21 250 Inboard Bearing Oil Seal 1 P25IBBOS 20620-01 H0620-01 5B-250-SEXI
    22 250 Outboard Bearing Oil Seal 1 P25OBBOS 20619-02 H20619-02 5A-250-OGSO
    23A 250 Power End Gasket Kit - P25PEGK 20625A H20625A 32-250-PEGK
    23 250 Inboard Bearing Cover Gasket 1 P25IBBCG 20625 H20625 3A-250-BCG
    24 250 Outbd. Bearing Hsg. Seal-Oring 1 P25OBBHS 7496-253 H7496-253 4D-250-BHOR
    25 250 Outbd. Brg. Cover Seal-Oring 1 P25OBBCS 7496-26 H7496-26 3B-250-BCOR
    26 250 Bearing Lock Nut Kit 1 P25BLNK 6123-4A H6123-4A 4E-250-BBLNA
    Note: XX or XXX Indicates Impeller Size
