HAMMER SEAL UNION (Tank Union) AND SEALS / Seal O-grip (Air O-Seal Union) and tubes / HAMMER UNION
| Place of Origin | China |
|---|---|
| Brand Name | BETTER |
| Certification | API 7K, 6A, 8C, ISO |
| Model Number | KEMPER |
| Minimum Order Quantity | 1 SET |
| Price | OFFER |
| Packaging Details | Carton, Plywood Case |
| Delivery Time | 7-10 days |
| Payment Terms | T/T, West Union |
| Supply Ability | Fast Delivery, Plenty in Stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Alloy | Technics | Casting |
|---|---|---|---|
| Type | Union | Connection | Welding |
| Shape | Equal | Head Code | Hexagon |
Product Description
BETTER Mud Tank Union is an updated design based on Air Grip Unions. These tank unions can accept pipe misalignment to finish an excellent connecting and sealing, and installation and uninstall rapidly, which has been widely used in mud tanks, mud tank connecting lines, and pump suction flanges.
BETTER manufactures and supplies unions for mud tanks, Hammerseal Unions, mud tank connecting lines and pump suction flanges. These are manufactured for a maximum line pressure of 150 PSI. The nitrile seal provides compressive seal, the cross-section of the seal designed to provide greater sealing surface. The union is designed to take a maximum of 7° misalignment on the pipe. Sizes which are catered for are 6", 8", 10" and 12", 6", 8" and 10" sizes can be socket welded to pipe or butt welded to tubing. 12" size requires butt weld. BETTER Mud Tank Union is an updated design based on Air Grip Unions. These tank unions can accept pipe misalignment to finish an excellent connecting and sealing, and installation and uninstall rapidly, which has been widely used in mud tanks, mud tank connecting lines, and pump suction flanges.
Both of BETTER Air Union and Tank Union styles are interchangeable with other major brands, Bulldog, C&C Industries, Kemper.
Features
Elongated cross-section of seal ring ensures greater sealing surface when in contact with the pipe makes up with hammer
Molded nitrile seal provides a compression seal
Tank union accepts up to 7 degree pipe misalignment
Available in3, 4, 6, 8, 10, 12, 14, 16, 18 and 20 inch sizes
Part no.: PS300A, PS400A, PS600A, PS800A, PS100A, PS120A, PS130A , PS140A, PS160A, PS180A, PS200A
Large diameter, medium-low voltage and frequently dismantling, rapid installation.
Technical parameter:
1. Medium available: mud, oil, water
2. Medium temperature:0°C~90°C
3. Ambient temperature:-30°C~50°C
4. Medium presssure:0.6Mpa
|
Type
|
Connect Pipe O.D.
|
Female Sub *
Weld to
|
Mud Tank Union Dimensions in mm
|
|||||||
|
A
|
B
|
C
|
D
|
E
|
F
|
G
|
H
|
|||
|
4-inch
|
4 ½”(114.3mm)
|
6”
|
264
|
168
|
150
|
127
|
50
|
155
|
114
|
21
|
|
6-inch
|
6 5/8”(168.3mm)
|
8”
|
340
|
219
|
200
|
127
|
50
|
208
|
168
|
21
|
|
8-inch
|
8 5/8”(219.1mm)
|
10”
|
343
|
273
|
253
|
127
|
50
|
258
|
219
|
21
|
|
10-inch
|
10 3/4” (273.1mm)
|
12”
|
432
|
325
|
305
|
127
|
50
|
311
|
273
|
21
|
|
12-inch
|
12 3/4”(323.9mm)
|
14”
|
491
|
355
|
336
|
127
|
50
|
364
|
324
|
21
|
|
14-inch
|
14” (355.6mm)
|
16”
|
557
|
406.4
|
381
|
127
|
50.8
|
395
|
356
|
21
|
|
16-inch*
|
16”(406.4mm)
|
18”
|
/
|
/
|
/
|
/
|
/
|
/
|
/
|
/
|
|
18-inch*
|
18”(457mm)
|
20”
|
/
|
/
|
/
|
/
|
/
|
/
|
/
|
/
|
|
20-inch*
|
20”(508mm)
|
22”
|
/
|
/
|
/
|
/
|
/
|
/
|
/
|
/
|
