Mechanical seal for Mission Magnum pump tungsten to tungsten face high quality

Mechanical seal for Mission Magnum pump tungsten to tungsten face high quality

    • Mechanical seal for Mission Magnum pump tungsten to tungsten face high quality
    • Mechanical seal for Mission Magnum pump tungsten to tungsten face high quality
    • Mechanical seal for Mission Magnum pump tungsten to tungsten face high quality
  • Mechanical seal for Mission Magnum pump tungsten to tungsten face high quality

    Product Details:

    Place of Origin: China
    Brand Name: BETTER
    Certification: API 7K, 6A, 8C, ISO
    Model Number: 2500

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: usd1500.00 per set
    Packaging Details: Carton, Plywood Case
    Delivery Time: 7-10 days
    Payment Terms: T/T, West Union
    Supply Ability: Fast Delivery, Plenty in Stock
    Contact Now
    Detailed Product Description
    Theory: Centrifugal Pump Structure: Single-stage Pump
    Usage: Slurry Power: 15kw-350kw
    Standard Or Nonstandard: Standard Fuel: Motor
    Pressure: Low Pressure Application: Charging Pump
    Speed: 800-2000 Rpm Color: Regular Blue, And Customized Color Acceptable

    BETTER is proud to offer Southwest cp250 replacement centrifugal pump and parts, and Offer the five star 2500 centrifugal pump series. BETTER series centrifugal sand pump are engineered for durable performance and pumping of various application, including:

    Triplex mud pump supercharging, liner washing pump, general charging pump, mud hopper & mud gun, trip tank, degasser, water pumping and mud cleaner and shale shaker.

    Complete Pump w/ casing and impeller
    BETTER MODEL SIZE Southwest part no. SEALING TYPE IMPELLER SIZE PART NO.
    BT-640202123-ITXX** 2 x 3 x 13 Y543252313 Mechanical Seal 13” 640202123ITA0
    BT-640202222-ITXX** 3 x 4 x 13 Y543254313 Mechanical Seal 13” 640202222ITA0
    BT-640202321-ITXX** 4 x 5 x 14 Y543255413 Mechanical Seal 14” 640202321ITA0
    BT-640202529-ITXX** 5 x 6 x 11 Y543253511 Mechanical Seal 11” 640202529ITA0
    BT-640202628-ITXX** 5 x 6 x 14 Y543256514 Mechanical Seal 14” 640202628ITA0
    BT-640202826-ITXX** 6 x 8 x 11 Y543256811 Mechanical Seal 11” 640202826ITA0
    BT-640202925-ITXX** 6 x 8 x 14 Y543256814 Mechanical Seal 14” 640202925ITA0
    Complete pump w/o casing & impeller Y543250000
    Complete rebuild w/o casing Repaircentpump



    BILL OF MATERIALS

    ITEM PART NUMBER DESCRIPTION QTY

    1 601102494-47 BOLT, GLAND ASSY 2

    2 601212392-47 KEY, 0.5 SQ X 3.0 LG 1

    3 641103296-47 COVER, BEARING, OUTBOARD 1

    4 641103338-47 GLAND ASSY, PACKING 1

    5 641116108-47 DEFLECTOR 1

    6 641116157-47 STUFFING BOX 1

    7 644302499-47 FRAME 1

    8 644303109-47 COVER, INBOARD BEARING 1

    9 644308504-47 HOUSING, OUTBOARD BEARING 1

    10 646490557-47 SHAFT 1

    11 641102182-47 SHAFT SLEEVE, STAINLESS STEEL 1

    12 648408706-47 GASKET, INBOARD BEARING 1

    13 648414308-47 MECHANICAL SEAL, TUNGSTEN 1

    14 661007005-47 PACKING, SHAFT 1

    15 109-0204 BALL BEARING, ANGULAR CONTACT 2

    16 109-0205 BEARING, ANGULAR CONTACT, DOUBLE ROW 1

    17 122-0267 SEAL, RADIAL, .313 X 2.750 X 1.875 1

    18 122-0268 RADIAL SHAFT SEAL, 3.5 X 2.5 X .438 1

    19 122-0269 EXCLUSION SEAL, 3.5 X 2.5 X .25 1

    20 126-0004 PLUG, HEX, SOCKET HEAD, 1/4 NPT 1

    21 126-0402 PLUG, SOCKET HEAD, 1/2" NPT 1

    22 129-0807 O-RING, 2-136 1

    23 129-0808 O-RING, 2-248 1

    24 129-0809 O-RING, 2-253 1

    25 134-1146 AN LOCK NUT, 11 1

    26 134-1147 AN LOCK WASHER, 11 1

    27 201-4215 CAPSCREW, HH, GR8, ZP, 3/8-16 UNC X 1 LG. 2

    28 201-4221 CAPSCREW, HH, GR8, ZP, 3/8-16 UNC X 2.50 LG. 2

    29 201-4392 CAPSCREW, HH, GR8, ZP, 1/2-13 UNC X 1.25 LG. 2

    30 201-4393 CAPSCREW, HH, GR8, ZP, 1/2-13 UNC X 1.50 LG. 8

    31 201-4675 CAPSCREW, HH, GR8, ZP, 3/4-10 UNC X 2 LG. 3

    32 203-0165 NUT, HEX, GR8, ZP, 1/2-13 UNC 2

    33 203-0824 NUT, LOCK, NYLON INS, GR8, ZP, 3/8-16 UNC 6

    34 204-0113 WASHER, FLAT, SAE, ZP, 3/8 10

    35 204-0115 WASHER, FLAT, SAE, ZP, 1/2 6

    36 210-5012 ZERK, GREASE, 1/8NPT 2

    37 210-5025 FITTING, GREASE, 90, 1/8 NPT 1

    38 210-5096 FITTING, GREASE, RELIEF, 1/8" NPT 1

    39 210-5133 FITTING, BREATHER, 1/8" 1

    Mechanical seal for Mission Magnum pump tungsten to tungsten face high quality
